Digital output data
The table shows the relation between the connector position and the output data allocation.
Table for output signal (EX600-DY*B)
Connector
position
Connector №
Output
Pin 2
signal
Pin 4
Outline dimensions
0
1
Bit 1
Bit 3
Bit 5
Bit 0
Bit 2
Bit 4
10.7
52.5
47
2
3
Bit 7
Bit 6
- 33 -
No.EX##-OML0007
