SMC Networks EX600-SDN Series Operation Manual page 56

Digital output unit parameters
Parameter
No
(EDS parameter)
Short circuit
detection
1
(Monitor short
circuit)
Restart after short
circuit
2
(Restart after short
circuit)
Open circuit
detection
3
(Monitor open circuit)
Output setting during
4
communication fault
(Fault action)
Output setting during
5
communication idle
(Idle mode)
Output ON/OFF
6 counter
(Switching counter)
Note) The idle mode can only be used if the connected PLC supports the idle function.
Setting
Value
Enable output short circuit
Enable
detection
Disable output short circuit
Disable
detection
After short circuit has been
Auto removed, the error will be cleared
automatically
After short circuit has been
removed, the error will not be
Manual
cleared until the power supply is
reset
Enable output open circuit
Enable
detection
Disable output open circuit
Disable
detection
During communication fault, clear
Clear
output
During communication fault hold
Hold
output
During communication fault, turn
Force On
ON output
During communication idle, clear
Clear
output
During communication idle, hold
Hold
output
During communication idle, turn
Force On
ON output
If output ON/OFF counter
Enable exceeds the set value, a
diagnostic error will be generated.
Diagnostic error will not be
Disable
generated
Set the maximum counter value.
Val Settable values are
(1~65000) x 1000 times
Contents
- 56 -
Setting Method
Setting Default
Level setting
By PLC By HT
O
Unit O
O
Unit O
Channel X
O
O
Channel X
O
Channel X
O
Channel X
65000
No.EX##-OML0007
O
O
O
O
O
O
