Name and function of the parts

1
5

Mounting and installation

Pin assignments
Pin No.
EX600-DYPB
1
2
3 0 V (for output)
4
5
Note) Output equipment with 4 pin M12 connector can also be connected to M12 (5 pin) connector
Wiring Diagram
▪ EX600-DYPB
DigitalOutput unit
1pin
NC
Short/Open
circuit
detection
2pin
Output2
3pin
0V
Short/Open
circuit
detection
4pin
Output1
5pin
FE
Be sure to place a seal cap on any unused connectors.
Placing the seal cap appropriately enables the unit to achieve IP67 protection.
2
3
4
Signal name
EX600-DYNB
NC 24 V (For output)
Output 2 Output 2
Output 1 Output 1
FE
End
plate
Power supply
for output
24VDC
FE
Name
No.
Indicates the unit status.
1 Status LED (Refer to the "Error display" section for
further details.)
Connector Connector for digital outputs.
2
(input) (M12, 5 pin, socket: SPEEDCON)
Marker
3
Groove to mount a marker.
groove
Joint bracket to join the adjacent unit,
4 Joint bracket
fixed with attached screws
Connector for Conveys the signals and power supplies
5
unit (plug) to the adjacent unit.
NC
FE
▪ EX600-DYNB
DigitalOutput unit
1pin
24V
2pin
Output2
3pin
NC
4pin
Output1
5pin
FE
