SMC Networks EX600-SDN Series Operation Manual page 69

Attribute
Access
ID
109 Get
160 Get
161 Get
162 Get
163 Get
164 Get
165 Get
166 Get
167 Get
102 Get/Set
Name
Number of units
Unit diagnostics 1
Unit diagnostics 2
Unit diagnostics 3
Unit diagnostics 4
Unit connection 1
Unit connection 2
Unit connection 3
Unit connection 4
Hold / Clear
Type Description / Value
USINT Number of connected units
Bit 0: Unit 0 diagnostic
Bit 1: Unit 1 diagnostic
Bit 2: Unit 2 diagnostic
Bit 3: Unit 3 diagnostic
Bit 4: Unit 4 diagnostic
Bit 5: Unit 5 diagnostic
Bit 6: Unit 6 diagnostic
Bit 7: Unit 7 diagnostic
WORD
Bit 8: Unit 8 diagnostic
Bit 9: Unit 9 diagnostic
Bit 10: (reserved)
Bit 11: (reserved)
Bit 12: (reserved)
Bit 13: (reserved)
Bit 14: (reserved)
Bit 15: (reserved)
WORD (reserved)
WORD (reserved)
WORD (reserved)
Bit 0: Unit 0 connection
Bit 1: Unit 1 connection
Bit 2: Unit 2 connection
Bit 3: Unit 3 connection
Bit 4: Unit 4 connection
Bit 5: Unit 5 connection
Bit 6: Unit 6 connection
Bit 7: Unit 7 connection
WORD
Bit 8: Unit 8 connection
Bit 9: Unit 9 connection
Bit 10: (reserved)
Bit 11: (reserved)
Bit 12: (reserved)
Bit 13: (reserved)
Bit 14: (reserved)
Bit 15: (reserved)
WORD (reserved)
WORD (reserved)
WORD (reserved)
BOOL 0 = Switch, 1 = Handheld
- 69 -
No.EX##-OML0007
