DeviceNet Object

EX600 supports the following object class.
Object
Identity
Message router
DeviceNet
Connection
Register
Acknowledge handler
Map
System
Generic unit
Digital input unit
Digital output unit
SI unit
Analog input unit
Map Object (65h)
Map object instance attribute
Attribute ID Access Name
100 Get
101 Get
Class No
01h
02h
03h
05h
07h
2Bh
65h
66h
67h
6Ah
6Bh
6Ch
6Dh
Input data size
Output data size
Instance
1
1
1
3
2
1
1
1
64
64
64
64
16
Type Description / Value
UINT Length of input data
UINT Length of output data
- 67 -
