Mounting and installation

Pin assignment
EX600-ED2
Pin No.
1
2
3 24 V (for control / input)
4
5
EX600-ED3
Pin No.
1
2
3
4 24 V (for control / input)
5
The power supplies.
This product has 2 power supplies and they are divided as follows.
Control and input power supply: supplies power for each control unit and for equipment connected to the
digital and analogue input units.
Output power supply: supplies power for equipment connected to the digital output units and for the
solenoid valve manifold.
Signal name
24 V (for output)
0 V (for output)
0 V (for output)
FE
Signal name
0 V (for output)
0 V (for output)
FE
24 V (for output)
Configuration
2 1
5
3 4
Configuration
5
1
2 4
3
