E Series 675/775
S e r v i c e M a n u a l
020-000546-04

Advertisement

Table of Contents
loading

Related Manuals for Christie E Series

Summary of Contents for Christie E Series

  • Page 1 E Series 675/775 S e r v i c e M a n u a l 020-000546-04...
  • Page 3 E Series 675/775 S e r v i c e M a n u a l 020-000546-04...
  • Page 4 Projector lamps (See Christie’s separate lamp program policy). c. Damage caused by use of a projector lamp beyond the recommended lamp life, or use of a lamp supplied by a supplier other than Christie. d. Problems caused by combination of the product with non-Christie equipment, such as distribution systems, cameras, video tape recorders, etc., or use of the product with any non-Christie interface device.

  • Page 5: Table Of Contents

    3.6.3 Color Wheel Index Adjustment ...................3-6 Procedure ..........................3-6 Inspection Item ........................3-7 Criteria ..........................3-7 3.7 Calibration ...........................3-8 3.7.1 F-type Fan Calibration ......................3-8 Procedure ..........................3-8 Criteria ..........................3-8 3.7.2 Dynamic Aperture Calibration.....................3-8 Procedure ..........................3-8 Inspection item ........................3-8 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 6 3.12.2 Network Setting ........................ 3-13 3.12.3 Read Projector information ....................3-13 3.13 Wireless Function Test ......................3-14 3.13.1 Setup Network Setting ...................... 3-14 3.13.2 Install Christie Presenter ....................3-14 3.13.3 Wireless Testing........................ 3-14 3.14 Boresight Alignment......................... 3-14 4: Troubleshooting 4.1 LED Status ..........................4-1 4.2 Low Light Output ........................
  • Page 7 5.2.15 Lamp Exhaust Fan ......................5-12 Procedure: ..........................5-12 5.2.16 Power Module Fan......................5-14 Procedure: ..........................5-14 5.2.17 Optical Fan.........................5-15 Procedure: ..........................5-15 5.2.18 Connector-A Board......................5-17 Procedure: ..........................5-17 5.2.19 Interlock Switch .........................5-20 Procedure: ..........................5-20 5.2.20 Lamp 1 Driver Board ......................5-20 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 8 6.1.1 Equipment Needed ......................6-1 Software ..........................6-1 Hardware ..........................6-1 6.1.2 Installation of the Firmware Upgrade Utility..............6-2 6.1.3 Firmware Upgrade Procedure ..................... 6-2 6.2 System Firmware Upgrade (Ethernet Method)................6-3 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 9 7.2.3 Video Signal Connectors .....................7-3 7.2.4 Power Connectors ........................7-3 7.2.5 Control Ports ........................7-4 7.2.6 Power Requirements ......................7-4 7.3 Lamp ............................7-4 7.3.1 Type .............................7-4 7.3.2 Operating Position .......................7-4 7.4 Physical Specifications ........................7-4 7.4.1 Dimensions ..........................7-4 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 10 A.8 ASSY Light Engine ........................A-9 A.9 Projector Labelling and Packaging .................... A-10 B: Serial Number Definition B.1 Serial Number Format for the Projector..................B-1 C: Schematic Diagrams C.1 I/O Board Schematics......................... C-1 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 11: Using This Manual

    E Series projectors. Projector Description The Christie E Series 675/775 projectors deliver up to 6,700/7,200 ANSI lumens and 5,000:1 contrast ratio; ideal for small auditoriums, and medium-to-large meeting, training, and conference rooms. The Christie DHD675-E and DHD775-E models offer native HD (1920 x 1080) resolution while the Christie DWU675-E and DW775-E provide WUXGA (1920 x 1200) resolution for maximizing image detail.

  • Page 13: 2: Service Guidelines

    Always power down and disconnect power sources prior to servicing. HIGH VOLTAGES MAY BE EXPOSED! Always unplug the projector prior to disassembly. CHRISTIE ACCREDITED SERVICE TECHNICIANS REQUIRED! All module replacement procedures must be performed by qualified service technicians. NON-INSULATED DANGEROUS VOLTAGES MAY BE EXPOSED! Always disconnect from AC prior to disassembly.

  • Page 14: Repair Cautions

    Position all cables where they cannot contact hot surfaces or be pulled or tripped over. All installation and maintenance procedures must be performed by a Christie accredited service technician. Projector must be operated in an environment that meets operating specifications.

  • Page 15: Servicing

    Section 2: Service Guidelines Servicing All servicing must be performed by CHRISTIE accredited service technicians. Use replacement parts that are manufacturer-approved only. Use of any other part other than the ones specified by the manufacturer can result in fire, electric shock or risk of personal injury and irreparable equipment damage.
  • Page 16 The projection lens should be free of dust and fingerprints. If the lenses must be cleaned, use a DRY soft cotton cloth. Rub gently in a circular motion. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 17: 3: Service Setup

    Section 3: Service Setup 3 Service Setup This section describes special adjustments and related details that may require the attention of a Christie accredited service technician, whether done periodically or after a specific module replacement. Factory Mode and Service Mode...
  • Page 18 Factory Status (Prism right sensor state. Prism left sensor state) - (Shutter Sensor State) - (Thermal external temperature) Test LED Mode Adjust Adjust source H,V position Driver Temper Displays internal temperature E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 19: Prism Offset

    After replacing the Lamp Module, reset lamp hours using the Remote or Built-in Keypad as follows: 1. Navigate to: Main Menu > Lamp > Reset Lamp Hours 2. Select 1, 2 or Both to reset the lamp hours. 3. Press E NTER E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 20: Test Equipment Needed

    Color Wheel index adjustment. • After changing parts, use Table 3.2 to determine appropriate updates to be performed. • After changing the F-type Fan (FAN6, FAN7, FAN8, FAN9), perform the F-type FAN calibration. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 21: Pc Mode

    • Test Pattern: Master, 64 gray RGBW or SMPTE bar. Use 480p, 720p, 1080p Mas- ter patterns to perform HDTV test. White should appear to be pure white (not exhibit color temperature shift). E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 22: Inspection Item

    2. Provide a 255 Gray Level test pattern to a projector input. 3. Select Color Speed. Pressing the Remote Controller or Keypad ENTER key will toggle this field between 2X and 3X. Select 2X. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 23: Inspection Item

    12. Check the 64 Gray RGBW pattern to ensure level changes are smooth. Inspection Item 255 Gray Level and 64 Gray RGBW patterns appear normal. Criteria Smooth gradations in patterns. No obvious steps in gray levels. Gradations Smooth Gradations ‘Stepped’ E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 24: Calibration

    DA is active. A change in brightness of the projected signal should occur as the sequence is performed. Inspection item Check if the brightness of the screen changes when performing the DA calibration. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 25: Lens Calibration

    3. Calibration pattern should be in full screen mode, navigate to: Main Menu > Size & Position > Size Presets > Full Size. 4. In factory mode, enter ADC Calibration, and press the H key to begin calibration. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 26: Inspection Item

    1. Display the Full White pattern. 2. Use a light meter to measure the brightness values of P1 to P9. 3. Follow the brightness formula to calculate brightness values. 4. Brightness Formula: Avg(P1~P9)*1.04m². 3-10 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 27: Criteria

    Dynamic Aperture Enabled: Full white to full dark contrast ratio--> 5000:1. 3.10.4 Uniformity Procedure 1. Display the Full White pattern. 2. Use a light meter to measure the brightness values of P1 to P13 (see Full white pattern image). E Series 675/775 Service Manual 3-11 020-000546-04 Rev. 1 (04-2017)

  • Page 28: Criteria

    Display Port Component S-Video CVBS RJ45 USB type B (mini) USB type A NOTE: There must be two input signals. “v” means the projector can display the two sources simultaneously. 3-12 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 29: Network Function Test

    3. Select Administrator for Access type. 4. Key in the password admin. 5. Click Login. 6. Confirm that the settings are the same as those recorded in 3.10.1. E Series 675/775 Service Manual 3-13 020-000546-04 Rev. 1 (04-2017)

  • Page 30: Wireless Function Test

    6. The projector screen will display the content which is the same as the PC. 3.14 Boresight Alignment • Boresight alignment is an advanced feature and should only be performed by a Christie accredited service technician. 1. Press TEST on the remote keypad to display the boresight test pattern.
  • Page 31 3 cap screws until the marks on the smaller and larger gears match up or are close to each other. 9. If further action is required. Repeat step 2. E Series 675/775 Service Manual 3-15 020-000546-04 Rev. 1 (04-2017)

  • Page 33: 4: Troubleshooting

    Projector is in OFF state (without AC connected) Projector is in standby mode (AC connected) Yellow (solid) Projector is in startup state Yellow long blink Projector is in cool down state Yellow long blink E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 34: Low Light Output

    Put the Chroma Meter in the center of the image. b. Then press <--or--> to find the brightest value. It should be 10 ±3. c. Measure the brightness of the unit. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 35: Equipment Required

    7. Put in new lamps to check if the low lumens is a problem due to the lamps. Equipment Required • Projector • PC (Personal computer) • DVD player • Screw drivers • VGA cable, power cord, component cable, audio cable & HDMI cable • Multimeter E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 36: Main Procedure

    Troubleshooting C. PIN Protect Is PIN protect on? Troubleshooting D. Image Is Image OK? Performance Troubleshooting E. Remote Remote Control Control Troubleshooting F. Network Is network OK? Troubleshooting No Fault Found E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 37: No Power Troubleshooting

    J1 of Main Change LVPS Board Pin1, 20 =5V? Change Main Board/Keypad Board Continue function test and other troubleshooting once power button backlight lit E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 38: Power Troubleshooting

    Section 4: Troubleshooting Power Troubleshooting E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 39 Section 4: Troubleshooting 4.6 Power Troubleshooting (continued) E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 40: Pin Protect Troubleshooting

    PIN correct? Show “Wrong PIN” message “power” button and press “Enter” button immediately PIN will be reset to default (Default PIN: Sequentially press these keys: 1, 2, 3, 4, 5) Normal operation E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 41: Image Performance Troubleshooting

    Section 4: Troubleshooting Image Performance Troubleshooting E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 42 Section 4: Troubleshooting 4.6 Image Performance Troubleshooting (continued) 4-10 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 43 Section 4: Troubleshooting 4.6 Image Performance Troubleshooting (continued) E Series 675/775 Service Manual 4-11 020-000546-04 Rev. 1 (04-2017)
  • Page 44 Section 4: Troubleshooting 4.6 Image Performance Troubleshooting (continued) 4-12 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 45: Remote Control Troubleshooting

    Can another function be used on Press the menu button on Does the OSD menu Replace the remote the remote the remote control show up on-screen? control control? No Fault Found E Series 675/775 Service Manual 4-13 020-000546-04 Rev. 1 (04-2017)

  • Page 46: Network Troubleshooting

    Section 4: Troubleshooting 4.10 Network Troubleshooting 4-14 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 47 Section 5: Parts and Module Replacement 5 Parts and Module Replacement This section contains information, instructions and guidelines for the replacement of serviceable parts and modules for the E Series projector. Table 5.1 E Series Service Parts List ITEM PART NAME/DESCRIPTION CHRISTIE SERVICE...

  • Page 48: Safety Warnings And Guidelines

    Section 5: Parts and Module Replacement Table 5.1 E Series Service Parts List ITEM PART NAME/DESCRIPTION CHRISTIE SERVICE KIT PART # ASSY Dynamic Aperture 003-004514-XX ASSY Switch Interlock 003-003499-XX ASSY PCB IR Sensor 003-004501-XX ASSY PCB Motor DC 003-003502-XX ASSY PCB DA Motor...

  • Page 49: Repair Cautions

    Position all cables where they cannot contact hot surfaces or be pulled or tripped over. All installation and maintenance procedures must be performed by a Christie accredited service technician. Projector must be operated in an environment that meets operating specifications.

  • Page 50: Replacement Procedures

    2. Hold lens in place and pull latch up to release as shown in Figure 5-1. 3. Pull lens out. NOTICE: Remove with care to avoid damage to FLC adaptor. 4. Install desired lens. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 51: Lamp Assembly

    1. Open lens top cover and remove screws (2). 5-3 T IGURE OVER CREWS 2. Loosen captive screws (2) and lift lamp access cover. 3. Remove screws (10). See Figure 5-3. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 52: Led Status Board

    5.2.6 LED Status Board Replacement Time: 15 minutes Procedure: 1. Remove Top Cover. See 5.2.5 Top Cover. 1. Remove screws (4). See Figure 5-6. 2. Replace board. 5-6 LED S IGURE TATUS OARD E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 53: Top Shield

    Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 3. Disconnect harness (Fan 7) from Connector-B Board. 4. Remove harness cable from retaining clips. 5. Remove screws (2). See Figure 5-8. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 54 IGURE OOLING ASKET 9. Install new fan. NOTICE: Make sure harness cable is routed as per Figure 5-10. 10. Connect harness (Fan 7 to Connector-B Board). 5-10 C IGURE OOLING ARNESS E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 55: Procedure

    3. Disconnect harness (Fan 12) from Connector-B Board and remove from cable clips. 4. Remove Color Wheel fan shield (2 screws) to access Prism Fan assembly casing screw. 5. Remove screws (4). See Figure 5-13. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 56: Color Wheel Fan

    11. Reassembly new Prism Fan assembly. 5.2.13Color Wheel Fan Replacement Time: 25 minutes Procedure: 1. Remove Top Cover. See 5.2.5 Top Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 5-10 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 57: Rear Exhaust Fans

    4. Remove screws (2) securing frame to base plate. See Figure 5-16. 5-16 R IGURE EMOVE XHAUST 5. Move top of frame towards center of projector to release it from the chassis and pull frame out. E Series 675/775 Service Manual 5-11 020-000546-04 Rev. 1 (04-2017)

  • Page 58: Lamp Exhaust Fan

    5.2.14 Rear Exhaust Fans. 5. Disconnect harness (Fan 8) from Connector-A Board. 6. Disconnect harness (Fan 9) from Connector-B Board. 7. Remove screws (4) securing metal cover. See Figure 5-19. 5-12 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 59 15. Install screws (4) to secure fan assembly to fan base 16. Insert new plastic ties (2) through fan base. 17. Tighten plastic ties to secure cables to fan base. 18. Route cable through cable clips. E Series 675/775 Service Manual 5-13 020-000546-04 Rev. 1 (04-2017)

  • Page 60: Procedure

    ARNESS 4. Remove harnesses from cable clip. 5. Remove screws (2) securing fan frame to chassis base. See Figure 5-23. 5-23 P IGURE OWER ODULE CREWS 6. Remove fan assembly. 5-14 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 61 3. Remove Cooling Fan - Lamp 1. See 5.2.9 Cooling Fan - Lamp 4. Disconnect all harnesses from Connector-B Board. Remove Connector-B Board (3 screws). See Figure 5- 5-26 C -B B IGURE ONNECTOR OARD E Series 675/775 Service Manual 5-15 020-000546-04 Rev. 1 (04-2017)

  • Page 62: Optical Fan

    9. Remove the Fan from the plastic frame. Note fan orientation before removing. See Figure 5-29. 5-29 R IGURE EMOVE PTICAL 10. Install the new Fan. Make sure the fan is installed in the proper orientation. 5-16 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 63: Procedure

    4. Remove screws (4). See Figure 5-30. 5-30 C -A B IGURE ONNECTOR OARD 5. Replace Connector-A Board. 6. Install screws (4). 7. Connect all harnesses to Connector-A Board. E Series 675/775 Service Manual 5-17 020-000546-04 Rev. 1 (04-2017)
  • Page 64 (4 pin) Lens Shift Sensor-V Composed of White/Yellow/ Black/Red Wire, White Connector and Red wire tube (4 pin) Prism-Motor Composed of Yellow/White/ Red/Blue Wire, White Connector and Black wire tube(4 pin) 5-18 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 65 Black wire tube (10 pin) Fan6-60X25-F Composed of Red/Blue/Black Wire, White Connector and Blue wire tube (3 pin) Composed of Green/Yellow/ White/Blue/Black/Red Wire, Gray Connector and Black wire tube (60 pin) E Series 675/775 Service Manual 5-19 020-000546-04 Rev. 1 (04-2017)
  • Page 66 UPPORT RACKET 5. Remove screws (2) securing Lamp 1 Driver Board. 6. Disconnect all harnesses from Lamp 1 Driver Board. 7. Lift Lamp 1 Driver board assembly out of projector. 5-20 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 67: Connector-A Board

    4. Disconnect Interlock harness. See 5.2.19 Interlock Switch. 5. Remove screws (5). See Figure 5-34. 5-34 R IGURE EMOVE OWER UPPLY OVER 6. Pull up Power Supply Cover assembly to expose harness underneath. E Series 675/775 Service Manual 5-21 020-000546-04 Rev. 1 (04-2017)

  • Page 68: Procedure

    4. Remove Power Supply Cover screws (5). See Figure 5-34. 5. Lift Power Supply Cover and disconnect all harnesses attached to components on Power Supply shield. 6. Remove Power Supply Cover. 7. Disconnect all harnesses attached to Power Supply. 5-22 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 69: Procedure

    11. Remove Power Supply Cover screws (5). See Figure 5-34. 12. Lift Power Supply Shield and disconnect all harnesses attached to components on Power Supply Cover. 13. Disconnect Lamp 1 harness from Lamp 1 Driver Board. E Series 675/775 Service Manual 5-23 020-000546-04 Rev. 1 (04-2017)

  • Page 70: Procedure

    • Remove Prism Motor bracket - Screws (2). 16. Replace Lamp Housing 5.2.24Back Panel Replacement Time: 20 minutes Procedure: 1. Remove Top Cover. See 5.2.5 Top Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 5-24 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 71: Procedure

    5.2.25Keypad Replacement Time: 25 minutes Procedure: 1. Remove Top Cover. See 5.2.5 Top Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 3. Remove Back Panel. See 5.2.24 Back Panel. E Series 675/775 Service Manual 5-25 020-000546-04 Rev. 1 (04-2017)

  • Page 72: Procedure

    Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 3. Remove Back Panel. See 5.2.24 Back Panel. 4. Remove Power Supply. See 5.2.22 Power Supply. 5. Disconnect from Power Supply. 5-26 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 73: Procedure

    Assembly. 4. Disconnect harnesses (2). 5. Remove screws (2). See Figure 5-46. 6. Replace Photo Sensor Board. 5 46 P IGURE HOTO ENSOR OARD 5.2.29Shutter Replacement Time: 25 minutes Procedure: E Series 675/775 Service Manual 5-27 020-000546-04 Rev. 1 (04-2017)

  • Page 74: Shutter

    6. Disconnect Shutter harness from Connector-A Board. 7. Disconnect Sensor harness from Connector-B Board. 8. Lift Shutter assembly out of projector. See Figure 5-49. 5-49 R IGURE EMOVE HUTTER SSEMBLY 9. Replace Shutter. 5-28 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 75: Procedure

    5.2.5 Top Cover. 2. Remove Top Shield. See 5.2.7 Top Shield. 3. Remove Prism Fan Assembly. See 5.2.12 Prism Fan Assembly. 4. Disconnect harnesses from DA Board and Connector-A Board. E Series 675/775 Service Manual 5-29 020-000546-04 Rev. 1 (04-2017)

  • Page 76: Dynamic Aperture

    Housing. NOTE: Lift Lamp Housing off Light Engine and move 9. Remove Lamp Housing. See 5.2.23 Lamp back. Do Not Remove. 10. Remove Cooling Fan - Lamp 2. See 5.2.10 Cooling Fan - Lamp 5-30 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 77: Light Engine

    Procedure: 1. Remove Light Engine. See 5.2.33 Light Engine. 2. Remove horizontal or vertical Lens Motor (2 screws). See Figure 5-55. 5-55 R IGURE EMOVE OTORS 3. Replace Lens Motor. E Series 675/775 Service Manual 5-31 020-000546-04 Rev. 1 (04-2017)

  • Page 78: Procedure

    3. Remove Dynamic Aperture. See 5.2.32 Dynamic Aperture. 5-57 R IGURE EMOVE 4. Remove screws (4). See Figure 5-57. 5. Lift off DMD Board. 6. Remove DMD from Light Engine. 7. Replace DMD. 5-32 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 79 4. Remove Main Board Shield. 5. Remove stand-offs (10) and screws (4). See Figure 5-40. 6. Remove screws (4) securing the PW610 board or the Dual Processor Warp Module. 7. Disconnect harnesses (4). E Series 675/775 Service Manual 5-33 020-000546-04 Rev. 1 (04-2017)
  • Page 80 14. Make sure the four switches on the main board module are in the right position as shown in Figure 5-61. a. The threes switches (SW2, SW7 and SW9) should be pushed to the “Normal” side. 5-34 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 81 If only switch “SW9” is not set properly and the other switches are set properly the symptom will be normal. 15. Perform procedure in 3.6.3 Color Wheel Index Adjustment. E Series 675/775 Service Manual 5-35 020-000546-04 Rev. 1 (04-2017)

  • Page 82: Procedure

    Replacement Time: 20 minutes Procedure: 1. Remove Main Board. See 5.2.38 Main Board. 2. Remove screws (3). See Figure 5-62. 5-62 R I/O B IGURE EMOVE OARD 3. Replace I/O Board. 5-36 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 83: Pwc808 Firmware Upgrade (Usb Method)

    6.1.1 Equipment Needed Software Use the relevant file for your operating system: • Christie ESeries PWC808_Bxxxx_x32_128M (32-bit operating systems) • Christie ESeries PWC808_Bxxxx_x64_128M (64-bit operating systems) NOTE: ''xxxx'' represents the software version. Example, “B21.37”. Hardware • Projector •...

  • Page 84: Installation Of The Firmware Upgrade Utility

    NOTE: The firmware upgrade procedure will begin automatically. When complete, the FlashUpgrader will display “Programming Complete”. 6. Set the projector to Factory Mode and verify that it is running the updated firmware version. Example “B21.37”. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 85: System Firmware Upgrade (Ethernet Method)

    6.2.1 Equipment Needed Software • Christie ESeries Cxxxx System FW LAN Update Wizard.exe NOTE: This file is extracted from Christie ESeries Cxxxx FW LAN Update Wizard.msi. ''xxxx'' represents the software version. Example, “C01.01”. Hardware • Projector • Power Cord •...

  • Page 86: Installation Of The Firmware Upgrade Utility

    2. Install the wizard file by executing the appropriate MSI installer package (example shown above is “Christie LAN Update Wizard.msi”). NOTE: If a prior version of the projectors firmware wizard is installed on your computer the following screen will appear. Otherwise continue to step 3 below.

  • Page 87: Sequence Code Upgrade Procedure

    This procedure upgrades the firmware that is resident on the projector’s LAN board, which provides the web interface for the projector. 6.3.1 Equipment Needed Software Christie Sequence Code LAN Update Wizard.exe Hardware • Projector • Power Cord • LAN Cable (RJ45) •...

  • Page 88: Firmware Upgrade Procedure

    Section 6: Firmware 6.3.2 Firmware Upgrade Procedure 1. Double-click on the Christie Sequence Code LAN Update Wizard. 2. Click Next. 3. Power on the projector. a. Connect the projector to AC power. b. Turn the projector on. c. Wait until the lamp(s) turn on and the source message is displayed on the bottom left of the projected image.

  • Page 89: Pic Fw Upgrade Procedure

    Software • Christie ESeries Axxxx PIC FW LAN Update Wizard.exe NOTE: This file is extracted from Christie ESeries Cxxxx FW LAN Update Wizard.msi. “xxxx” is the version number, Example C01.01 msi fle will contain the PIC FW A29.02 .exe file.
  • Page 90 Enter the projector IP address. e. Click Next. 5. Click Next. NOTE: The firmware will begin the upgrading. 6. When complete, verify that the projector is running the updated firmware version. Example, version A29.02. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 91: Display

    • Dual 350W with 6S High Brightness Color Wheel (RGBCYW): Typical 6400 lm • Dual 350W with 6S “Best Color” Color Wheel (RGBCYM): Typical 4300 lm 7.1.3 Achievable Contrast Ratio ANSI: 16 pt checker pattern on black screen • 250:1 ANSI E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 92: Dynamic Aperture Enabled

    6S “Best Color” color wheel ± Green x: 0.299 0.02 (RGBCMY) ± y: 0.650 0.02 ± Blue x: 0.140 0.02 ± y: 0.077 0.02 7.1.7 Keystone Correction ± • 20 degrees E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 93: Inputs

    • RGBHV x1 set, BNC 75 Ohm, Female • Display Port x1, version 1.1a • USB Type B mini x1 • USB Type A x1 • RJ45 x1 7.2.4 Power Connectors • AC Mains In x1, IEC/EN60320-C13 receptacle E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 94: Control Ports

    • Product: (L x W x H) 532 x 456 x 215 (mm) (excluding feet & with lens removed) • Shipping: (L x W x H) 591 x 965 x 0.390 (mm) 7.4.2 Weight • Product: < 19.5kg (with lens removed) • Shipping: <26.3kg (includes packaging) E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 95: Reliability

    • Operating range 5 to 30 degrees C (5000~10000 ft) • Storage temperature range -10 to +60 degrees C 7.7.2 Humidity • 0% to 80% RH (Max.), non condensing 7.7.3 Altitude • Operating Altitude 10,000 ft maximum E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 96: Standard And Optional Components

    Lamp Module with installed lamp (DHD775-E/DWU775-E) 003-004450-XX C/W. Max Brightness (RGBCYW) 003-003410-XX C/W. Best Color (RGBCMY) 003-003411-XX Locking HDMI to DVI adapter 003-003671-XX Warping Board 133-111104-XX Wireless Dongle 133-113106-XX Stacker 133-107109-XX E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 97: General Exploded View

    Appendix A: Exploded Views A.1 General Exploded View NOTE: This chapter is only designed to show the exploded image of the projector. For updated part numbers, please refer to RSPL report. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 98 ASSY PCB Main (DHD675-E) 003-004542-XX ASSY PCB Main (DWU775-E) 003-004540-XX ASSY PCB Main (DHD775-E) 003-004515-XX ASSY Door Motherboard 003-004494-XX ASSY PCB PW610 (standard) 133-111104-XX Dual Processor Warp Module (optional replacement for PW610) E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 99: Assy Cover Front

    ASSY Cover Front (DHD775-E) 003-004543-XX ASSY Cover Front (DWU775-E) 003-003490-XX ASSY Logo Christie Badge 003-003803-XX ASSY Cover Front IR 013-101313-XX Label ID DLP Logo 003-004501-XX ASSY PCB Sensor IR 003-003633-XX ASSY Lens Rubber Gasket E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 100: Assy Cover Rear

    Appendix A: Exploded Views A.3 ASSY Cover Rear Table A.3 ASSY Cover Rear Parts List ITEM DESCRIPTION 003-004511-XX ASSY Cover Rear 003-003807-XX ASSY Keypad Rubber 003-004498-XX ASSY PCB Keypad E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 101: Assy Cover Top

    Appendix A: Exploded Views A.4 ASSY Cover Top Table A.4 ASSY Cover Top Parts List ITEM DESCRIPTION 003-004518-XX ASSY Cover Top 003-004526-XX ASSY PCB LED E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 102: Assy Lamp Driver (Right

    Table A.5 ASSY Lamp Driver (Right) Parts List ITEM DESCRIPTION 003-004524-XX ASSY PCB Connector A 003-003552-XX ASSY Lamp Driver Module (DHD675-E/DWU675-E) 003-004530-XX ASSY Lamp Driver Module (DHD775-E/DWU775-E) 003-003499-XX ASSY Switch Interlock E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 103: Assy Lamp Driver (Left

    Appendix A: Exploded Views A.6 ASSY Lamp Driver (Left) Table A.6 ASSY Lamp Driver (Left) Parts List ITEM DESCRIPTION 003-003552-XX ASSY Lamp Driver Module (DHD675-E/DWU675-E) 003-004530-XX ASSY Lamp Driver Module (DHD775-E/DWU775-E) E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 104: Assy Pcb Main

    ASSY PCB Main (DWU675-E) 003-004512-XX ASSY PCB Main (DHD675-E) 003-004542-XX ASSY PCB Main (DWU775-E) 003-004540-XX ASSY PCB Main (DHD775-E) 003-004494-XX ASSY PCB PW610 (standard) 133-111104-XX Dual Processor Warp Module (optional replacement for PW610) E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 105: Assy Light Engine

    003-003497-XX ASSY Housing Lamp 003-004519-XX ASSY PCB DYN Aperture Motor 003-004544-XX ASSY CW Brightness E Series 003-003411-XX ASSY CW Color E Series (optional color wheel) 003-004514-XX ASSY DYN Aperture Module 003-004516-XX ASSY Shutter Module 003-003481-XX ASSY Blower Fan 50x50x20 E Series 675/775 Service Manual...

  • Page 106: Projector Labelling And Packaging

    Appendix A: Exploded Views A.9 Projector Labelling and Packaging A-10 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 107 DWU775-E, without lens 133-008110-XX DWU775-E (China), without lens 133-008121-XX DWU775-E (Korea), without lens 003-003489-XX ASSY Carton 003-004469-XX Remote for Christie WUXGA/1080P 003-003671-XX ASSY Cable HDMI-DVI Female 12 020-000515-XX E Series User Manual E Series 675/775 Service Manual A-11 020-000546-04 Rev. 1 (04-2017)

  • Page 109: Serial Number Format For The Projector

    008 = Serial Numbers 031023008 Example: This label represents the serial number for a DHD675-E projector. It is produced on the 23th week of 2010 and the serial number is 008. E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)

  • Page 111: I/O Board Schematics

    Appendix C: Schematic Diagrams C.1 I/O Board Schematics E Series 675/775 Service Manual 020-000546-04 Rev. 1 (04-2017)
  • Page 113 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 114 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 115 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 116 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 117 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 118 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 119 Appendix C: Schematic Diagrams E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 120 Appendix C: Schematic Diagrams C-10 E Series 675/775 Service Manual 020-000546-04 Rev. 1 (03-2017)
  • Page 122 Corporate offi ces Worldwide offi ces USA – Cypress United Kingdom Eastern Europe Singapore Japan ph: 714-236-8610 ph: +44 118 977 8000 ph: +36 (0) 1 47 48 100 ph: +65 6877-8737 ph: 81-3-3599-7481 Canada – Kitchener France Middle East Beijing South Korea ph: 519-744-8005...
