Before installing an RMR be sure you have prepared the UPS according to the
instructions on page 19. You can install up to two RMPs or up to two RIMS, or one
of each.
install an RMP:
To
I
2. Install wiring from the RMP through l/2" condutt and through the l/2" knockout
I
I
3. In the hardware kit, locate the terminal block bracket (see Figure 39).
I
I
I
I
I
I
I
I
in either the top or bottom of the UPS cabinet.
The top entry connection requires installation of l/2" flexible conduit within the
UPS. Bottom entry connection requires no additional routing of conduit within
the UPS.
Connect to
Connect to
Port 1 (DE-g)
Port 1 (DE-g)
on Customer
on Customer
Interface Panel
Interface Panel
Plug the connector on the back of the terminal block into the DE-9 connector
on the Communications Panel of the UPS (see Figure 31). Use two screws from
the hardware kit to secure the terminal block bracket to the Communications
Panel.
TERMINAL
TERMINAL
