7. Remove the nut from the screw in the lower door hinge of the UPS
8.
I
(see Figure 15 on page 24)
I
I
I
I
L o w e r -
door hinge
I
I
I
I
I
I
11.
I
24
Hold the angled bracket parallel to the floor (see Figure 15). The flange with the
hole in it (labeled A in the figure) should be facing upward. The flange with the
tab (labeled B in the figure) should be pointing toward the slot in the base of the
optional cabinet.
Slide the bracket toward the UPS cabinet while slipping the hole (A) onto the
screw in the lower door hinge of the UPS cabinet
Replace the nut (removed in step 7 on page 24) on the hinge screw to secure
the angled bracket in place.
the UPS cabinet.
