To install a caster assembly:
with any part of the caster assembly, do not install the assembly. Contact
Customer Support and report the.problem.
lockwashers. Remove the envelope and set it aside. Close the cabinet door.
openings on the bottom of the cabinet.
Each caster assembly fits on four studs (two at the front and two at the back) on
the bottom of the cabinet (see Figure 7). There are holes in the caster assembly
that fit over these studs.
(view from underneath)
Because of the height of the caster assembly, you cannot hold the assembly
parallel with the base of the cabinet while you slide it into the channel. Tilt the
inner edge of the assembly upward to slide it into the channel (see figure 8).
Power-ware Plus 80 UPS Installation Manual
UPS CABINET
F/gum 1. Battam Mew, Cabinet w/M Cmiera Installed
