  • Page 1 ® Powerware 5125 Tower User’s Guide 1000–2200 VA www.powerware.com...
  • Page 2 Powerware is a registered trademark and Advanced Battery Management Plus (ABM Plus), X-Slot, and ConnectUPS are trademarks of Powerware Corporation. C opyright 2001 Powerware Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Powerware Corporation.
  • Page 3 Class A EMC Statements (1000–1500 VA Models) FCC Part 15 NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Special Symbols

    Special Symbols The following are examples of symbols used on the UPS to alert you to important information: RISK OF ELECTRIC SHOCK associated warning should be observed. CAUTION: REFER TO OPERATOR’S MANUAL additional information, such as important operating and maintenance instructions.

  • Page 5: Table Of Contents

    ABLE OF 1 Powerware 5125 – One of the Best! 2 Safety Warnings ..........
  • Page 6 ............Powerware 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com...

  • Page 7: Powerware 5125 - One Of The Best

    — causing hours of lost productivity and expensive repairs. With the Powerware 5125, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. The Powerware 5125 was designed for critical applications such as PCs, severs, workstations, and telecommunications equipment.
  • Page 8 Low voltage models can also protect modems, fax machines, or other telecommunications equipment. Optional X-Slot capabilities for increased power protection and control. The Powerware 5125 is backed by worldwide agency approvals. Powerware ) doubles battery modules provide enhanced communication 5125 Tower (1000–2200 VA) User’s Guide...

  • Page 9: Safety Warnings

    To comply with international standards and wiring regulations, the total equipment connected to the output of this UPS must not have an earth leakage current greater than 1.5 milliamperes. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® D A N G E R W A R N I N G C (104 F ).
  • Page 10 1,5 milliampere. Powerware C A U T I O N F A R E A D V A R S E L ! C . UPS’en bør ikke betjenes nær ° 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 11 Batterier kan udgøre en fare for elektrisk stød eller forbrændinger forårsaget af høj kortslutningsspænding. De korrekte forholdsregler bør overholdes. Korrekt bortskaffelse af batterier er påkrævet. Overhold gældende lokale regler for bortskaffelsesprocedurer. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® A D V A R S E L Rev B www.powerware.com Safety Warnings...
  • Page 12 1,5 milliampeeria (mA). Powerware O P G E L E T V A A R A V A R O I T U S C . Älä käytä lähellä vettä ° 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 13 à la terre de la totalité du matériel branché sur la sortie de l’onduleur ne doit pas dépasser 1,5 mA. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® V A R O D A N G E R ! A V E R T I S S E M E N T ! C .
  • Page 14 Erdschlußstrom von insgesamt 1,5 Milliampere nicht überschreiten. Powerware A T T E N T I O N ! W A R N U N G A C H T U N G 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ® °...
  • Page 15                                   Powerware 5125 Tower (1000–2200 VA) User’s Guide ® V O R S I C H T !
  • Page 16 Safety Warnings Avvisi di sicurezza IMPORTANTI ISTRUZIONI DI SICUREZZA CONSERVARE QUESTE ISTRUZIONI QUESTO MANUALE CONTIENE IMPORTANTI ISTRUZIONI DI Powerware      5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 17 Romtemperaturen må ikke overskride 40 ikke brukes i nærheten av vann eller ved meget høy luftfuktighet (95% maks.). Powerware 5125 Tower (1000–2200 VA) User’s Guide ® A T T E N Z I O N E F A R L I G F A R L I G Rev B www.powerware.com...
  • Page 18 F O R S I K T I G C U I D A D O A D V E R T Ê N C I A C . Não opere próximo a ° 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 19 окружающего воздуха не должна превышать 40 эксплуатируйте устройство около воды или в местах с повышенной влажностью (макс. 95%). Powerware 5125 Tower (1000–2200 VA) User’s Guide ® P E R I G O О П А С Н О П Р Е Д У П Р Е Ж Д Е Н И Е...
  • Page 20 SIE. Powerware О С Т О Р О Ж Н О P E L I G R O A D V E R T E N C I A 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 21 Ta aldrig bort nätsladden när UPS-enheten är påslagen. Detta tar bort skyddsjordningen från både UPS-enheten och den anslutna utrustningen. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® P R E C A U C I Ó N F A R A V A R N I N G Rev B www.powerware.com...
  • Page 22 Batterierna kan ge elektriska stötar eller brännskador från hög kortslutningsström. Följ tillämpliga anvisningar. Batterierna måste avyttras enligt anvisningarna i lokal lagstiftning. Använda batterier får aldrig brännas upp. De kan explodera. Powerware V I K T I G T 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ® °...

  • Page 23: Installation

    3. If a second EBM is to be installed, plug the EBM cable of the second cabinet into the battery connector on the first EBM. Up to four EBMs may be connected to the UPS. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® Rev B www.powerware.com...
  • Page 24 Powerware Communication Port EBM Battery Connector Power Cord Output Receptacles Figure 2. Typical Installation with Two EBMs µ i ndicator flashes, 5125 Tower (1000–2200 VA) User’s Guide ® EBM Cable Rev B www.powerware.com...
  • Page 25 24 hours after installation or long-term storage. NOTE If more than two EBMs are installed, an external battery charger is recommended for faster recharge times. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® µ i ndicator stops flashing Rev B www.powerware.com...

  • Page 26: Ups Rear Panels

    Installation UPS Rear Panels This section shows the rear panels of the Powerware 5125 models. X-Slot Powerware 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 27 Communication Port X-Slot 10A, IEC-320 Input Connector Battery Connector Figure 5. PW5125 1000i and PW5125 1500i Rear Panel Powerware 5125 Tower (1000–2200 VA) User’s Guide ® Rev B www.powerware.com Installation Network Transient Protector Six 10A, IEC 320-C13 Receptacles...
  • Page 28 Installation Powerware 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 29 Communication Port X-Slot Battery Connector Powerware 5125 Tower (1000–2200 VA) User’s Guide ® 6-ft Power Cord with L5-30 Plug Figure 9. PW5125 2200j Rear Panel Rev B www.powerware.com Installation Network Transient Protector Six 5-15R Receptacles Two 5-20R Receptacles Network Transient...
  • Page 30 Installation Powerware 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 31: Operation

    Turning the UPS on and off Starting the UPS on battery Initiating the self-test Operating Modes Powerware 5125’s front panel indicates the UPS status through the UPS indicators. Figure 11 shows the UPS front panel indicators and controls. Powerware 5125 Tower (1000–2200 VA) User’s Guide ®...

  • Page 32: Normal Mode

    >100% 76–100% 51–75% 26–50% 0–25% Figure 12. Load Level Indicators indicator are Buck Mode Single Boost Mode Double Boost Mode Figure 13. Buck and Double Boost Indicators 5125 Tower (1000–2200 VA) User’s Guide ® µ i ndicator Rev B www.powerware.com...

  • Page 33: Battery Mode

    To turn on the UPS without using utility power, press and hold the On button for at least four seconds. The UPS supplies power to your equipment and goes into Battery mode. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® µ i ndicator flashes and the bar graph 10%), the UPS shuts down the load.

  • Page 34: Turning The Ups Off

    UPS are checked. If the alarm beeps or a UPS alarm indicator stays on, see Table 9 on page 44. Powerware button until the long µ i ndicator begins to button for three seconds to initiate the self-test. 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 35: Additional Ups Features

    X-Slot modules allow the UPS to communicate in a variety of networking environments and with different types of devices. The Powerware 5125 is factory-installed with a Single-Port module and is compatible with any X-Slot module, including: Multi-Server Module - has six serial communication ports that can communicate with UPSs, terminals, computers, and modems.

  • Page 36: Single-Port Module

    Additional UPS Features Single-Port Module The Powerware 5125 is factory-installed with a Single-Port Module. To establish communication between the UPS and a computer, connect your computer to the UPS communication port using the supplied communication cable. When the communication cable is installed, power management software can exchange data with the UPS.

  • Page 37: Network Transient Protector

    Connect the input connector of the equipment you are protecting to the jack labeled IN. Connect the output connector to the jack labeled OUT. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® Figure 16. Network Transient Protector Rev B www.powerware.com...

  • Page 38: Load Segments

    NOTE If the power management software is not used, the individual load segments cannot be controlled. The following figures show the load segments for each UPS. 100V/120V Models Powerware Load Segment 1 Load Segment 2 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 39: Ups Maintenance

    Conduct a self-test by pressing and holding the contact your service representative to order new batteries. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® button for three seconds. If the indicator stays on, Rev B www.powerware.com...

  • Page 40: Replacing Batteries

    EBM. Powerware button until the long beep ceases (approximately five W A R N I N G UPS Battery Connector Figure 19. EBM Connections (120V Model Shown) 5125 Tower (1000–2200 VA) User’s Guide ® Battery Connector Cable Rev B www.powerware.com...

  • Page 41: How To Replace Internal Batteries

    UPS. Use the following procedure to replace internal batteries: 1. Remove the UPS front panel by pulling the top. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® C A U T I O N Rev B www.powerware.com...
  • Page 42 See “Recycling the Used Battery” on page 38 for proper disposal. Powerware Disconnect the red battery cable on the front of the 1000 VA 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 43: Testing New Batteries

    1500 and 2200 VA units. surface. Press on the black tab on the battery cable connector to disconnect the battery. See “Recycling the Used Battery” on page 38 for proper disposal. Powerware 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 44: Recycling The Used Battery

    For more information, contact your local recycling or hazardous waste center. Powerware W A R N I N G C A U T I O N 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...

  • Page 45: Specifications

    C H A P T E R 7 PECIFICATIONS This section provides the following specifications for the Powerware 5125 models: Electrical input and output Weights and dimensions Environmental and safety Battery Table 2. Model Specifications Power Levels Model Number (rated at nominal inputs)
  • Page 46 PW5125 1500j Powerware Output Receptacles (6) 5-15R (6) 5-15R (6) 5-15R (2) 5-20R (9) 10A, IEC 320-C13 (6) 10A, IEC 320-C13 (6) 10A, IEC 320-C13 (9) 10A, IEC 320-C13 (6) 5-15R 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ®...
  • Page 47 2 EBM Monitoring Advanced monitoring for earlier failure detection and warning; auto detection of additional EBMs Powerware 5125 Tower (1000–2200 VA) User’s Guide ® High Voltage Models 10°C to 40°C (50°F to 104°F) Optimal battery performance: 25°C (77°F) 0°C to 25°C (32°F to 77°F)
  • Page 48 N N N N O O O O T T T T E E E E Powerware 1 EBM 2 EBMs 3 EBMs 25/60 55/170 83/199 33/79 63/146 92/174 26/60 55/170 81/198 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ® 4 EBMs 109/228 120/201 106/224...

  • Page 49: Troubleshooting

    Use Table 9 to determine and resolve the UPS alarms and conditions. General Alarm On Battery Battery Service Site Wiring Fault Power On Figure 20. Alarm Indicators Powerware 5125 Tower (1000–2200 VA) User’s Guide ® On Button Off Button Test/Alarm Reset Button Rev B www.powerware.com Indicator Legend Unlit Green...

  • Page 50: Silencing An Audible Alarm

    3 minutes or less of battery power remains (depending on load configuration and battery charge). Save your work and turn off your equipment. The alarm cannot be silenced. 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com ® button. If UPS...
  • Page 51 1 beep every 5 seconds. discharged. The battery is not connected correctly. Powerware 5125 Tower (1000–2200 VA) User’s Guide ® Action Correct the input voltage, if possible. The UPS continues to operate on battery until the condition is corrected or the battery is completely discharged.

  • Page 52: Service And Support

    + + + + 6 6 6 6 1 1 1 1 - - - - 3 3 3 3 - - - - 9 9 9 9 7 7 7 7 0 0 0 0 6 6 6 6 - - - - 5 5 5 5 0 0 0 0 2 2 2 2 2 2 2 2 5125 Tower (1000–2200 VA) User’s Guide Rev B www.powerware.com...
