  • Page 1 ® Powerware 9125 User’s Guide 2500–3000 VA www.powerware.com...
  • Page 2 Powerware is a registered trademark and Fourth-Generation Online, Advanced Battery Management Plus (ABM Plus), X-Slot, and ConnectUPS are trademarks of Powerware Corporation. Copyright 2002 Powerware Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Powerware Corporation.
  • Page 3 Class A EMC Statements FCC Part 15 NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Special Symbols The following are examples of symbols used on the UPS to alert you to important information: RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the associated warning should be observed. CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for additional information, such as important operating and maintenance instructions.

  • Page 5: Table Of Contents

    ABLE OF ONTENTS 1 Powerware 9125 – The Ultimate Online UPS! ......2 Safety Warnings .
  • Page 6 ............Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com...

  • Page 7: Powerware 9125 - The Ultimate Online Ups

    — causing hours of lost productivity and expensive repairs. With the Powerware 9125, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Figure 1 shows the Powerware 9125 UPS with an optional Extended Battery Module (EBM).
  • Page 8 : Flash memory provides easy upgrades or reconfiguration capability without requiring a service call. : The Powerware 9125 is backed by worldwide agency approvals. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com...

  • Page 9: Safety Warnings

    For UPS models with hardwired outputs, overcurrent protection for the output AC circuit(s) is to be provided by others. For UPS models with hardwired outputs, suitably rated disconnect switches for the output AC circuit(s) are to be provided by others. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 10 I overensstemmelse med internationale normer og bestemmelser for el-installation må det udstyr, der er forbundet til udgangen af denne UPS, tilsammen ikke overskride en jordafdelingsspænding på mere end 1,5 milliampere. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 11 Verwijder de ingangsnoer niet of haal de stekker van de ingangsnoer er niet uit terwijl de UPS aan staat. Hierdoor zou de UPS en uw aangesloten apparatuur geen aardebeveiliging meer hebben. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 12 Volg de desbetreffende aanwijzingen op. De batterijen moeten op de juiste wijze worden opgeruimd. Raadpleeg hiervoor uw plaatselijke voorschriften. Nooit batterijen in het vuur gooien. De batterijen kunnen ontploffen. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 13 Akusto saattaa aiheuttaa sähköiskun tai syttyä tuleen, jos akusto kytketään oikosulkuun. Noudata asianmukaisia ohjeita. Akusto täytyy hävittää säädösten mukaisella tavalla. Noudata paikallisia määräyksiä. Älä koskaan heitä akkuja tuleen. Ne voivat räjähtää. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 14 Pour les models UPS ayant des sorties câblées, les interrupteurs de déconnexion convenables pour le(s) circuit(s) de sortie de courant alternatif doivent être fournie par un autre fournisseur. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 15 Luftfeuchtigkeit (max. 95 %) betreiben. Um internationale Normen und Verdrahtungsvorschriften zu erfüllen, dürfen die an den Ausgang dieser USV angeschlossenen Geräte zusammen einen Erdschlußstrom von insgesamt 1,5 Milliampere nicht überschreiten. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 16 Ìçí âãÜæåôå áðü ôçí ðñßæá ôï êáëþäéï ôñïöïäïóßáò üôáí ôï UPS åßíáé áíïé÷ôü. Ì áõôü ôïí ôñüðï áöáéñåßôå ôç ãåßùóç áóöáëåßáò áðü ôï UPS êáé áðü ôïí åîïðëéóìü ðïõ åßíáé óõíäåäåìÝíïò ìå ôï UPS. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 17 áðü õøçëü ñåýìá âñá÷õêõêëþìáôïò. ËáìâÜíåôå ôéò êáôÜëëçëåò ðñïöõëÜîåéò. Áðáéôåßôáé óùóôÞ äéÜèåóç ôùí óõóóùñåõôþí. Äåßôå ôïõò ôïðéêïýò êáíïíéóìïýò ðïõ áöïñïýí ôéò áðáéôÞóåéò äéÜèåóÞò ôïõò. ÐïôÝ ìçí ðåôÜôå ôïõò óõóóùñåõôÝò óôç öùôéÜ, ãéáôß ìðïñåß íá åêñáãïýí. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 18 Nei sistemi UPS provvisti di uscite cablate, i sezionatori di corrente nominale adeguata per il/i circuito/i a corrente alternata in uscita devono essere forniti da terzi. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 19 For UPS systemer med fastkoplete uttak, må overstrømvern for vekselstrømuttak(ene) stilles til rådighet av andre. For UPS systemer med fastkoplete uttak, må passende utkoplingsbrytere for vekselstrømuttak(ene) stilles til rådighet av andre. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 20 Para estar de acordo com os padrões internacionais e os regulamentos de fiação, o equipamento total conectado à saída desta UPS não deve ter uma corrente de fuga à terra maior que 1,5 miliampères. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 21 даже когда ИБП не подключен к сети переменного тока. Не отсоединяйте сетевой шнур и не извлекайте его вилку из розетки при включенном ИБП. При этом защитное заземление отключается от ИБП и от оборудования, подключенного к ИПБ. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 22 соответствующие меры предосторожности. Необходимо соблюдать правила утилизации аккумуляторов. Обратитесь к местным нормативным актам за информацией о требованиях к утилизации. Никогда не бросайте аккумуляторы в огонь. Аккумуляторы могут взорваться под воздействием огня. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 23 CA de salida será suministrada por terceros. Para los sistemas UPS con salidas cableadas permanentemente, los interruptores de desconexión debidamente clasificados para el/los circuito(s) de CA de salida serán suministrados por terceros. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 24 Använd inte utrustningen nära vatten eller vid hög luftfuktighet (max 95 %). För att överensstämma med internationell standard och installationsföreskrifter får inte den totala utrustning som anslutits till uttagen på denna UPS-enhet ha läcksström som överstiger 1,5 milliampere. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 25 Batterierna kan ge elektriska stötar eller brännskador från hög kortslutningsström. Följ tillämpliga anvisningar. Batterierna måste avyttras enligt anvisningarna i lokal lagstiftning. Använda batterier får aldrig brännas upp. De kan explodera. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 26 Safety Warnings Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 27: Installation

    UPS. Contact your service representative. UPS Setup The Powerware 9125 UPS is designed for flexible configurations and can be installed in a rack or as a standalone cabinet. If you are installing the UPS in a rack, continue to the following section “Rack-Mount Setup;”...

  • Page 28: Rack-Mount Setup

    UPS and secure with the supplied screws (see Figure 2). 4. If installing optional EBMs, repeat Steps 1 through 3 for each cabinet. Mounting Bracket Mounting Handle Figure 2. Installing the Mounting Brackets Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 29: Tower Setup

    3. Position the pedestals over the end of the UPS cabinet so that the weight of the unit is evenly distributed. Secure the pedestals with the screws provided in the accessory kit. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 30 Figure 5. Pedestals with One Cabinet 5. Place the UPS cabinet horizontally so that the left end of the unit is accessible (see Figure 6). Figure 6. Installing UPS Pedestals with Two Cabinets Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 31 8. Carefully position the cabinets upright with the air vents at the top (see Figure 8 or Figure 9). Air Vents Figure 8. Pedestals with Two Cabinets Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 32 EBM Bracket Figure 10. Installing the EBM Brackets (Top View with Pedestals) 10. If installing additional EBMs, repeat Step 9 for each cabinet and continue to the following section, “EBM Installation.” Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 33: Ebm Installation

    4. Continue to “Plug-Receptacle UPS Installation” on page 30 or “Hardwired UPS Installation” on page 32. UPS Battery Connector EBM Cable EBM Battery Connectors Figure 11. Typical EBM Installation (120V UPS Model Shown) Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 34 NOTE Keep the EBM cable cover for future use. If the EBM is stored or removed from the UPS, the EBM cable cover must be installed as a safety precaution. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 35 Repeat for each additional EBM. Up to four EBMs may be connected to the UPS. 10. Continue to the following section, “Plug-Receptacle UPS Installation” or “Hardwired UPS Installation” on page 32. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 36: Plug-Receptacle Ups Installation

    3. If an emergency power-off (disconnect) switch is required by local codes, see “Remote Emergency Power-Off” on page 36 to install the REPO switch before powering on the UPS. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 37 The UPS is now in Normal mode and supplying power to your equipment. NOTE The batteries charge to 90% capacity in approximately 3 hours. However, it is recommended that the batteries charge for 24 hours after installation or long-term storage. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 38: Hardwired Ups Installation

    For UPS models with hardwired outputs, suitably rated disconnect switches for the output AC circuit(s) are to be provided by others. The Powerware 9125 requires a dedicated branch circuit that meets the following requirements: : 16A, 2-pole circuit breaker for EH models/20A, 2-pole circuit breaker...
  • Page 39 5. Insert each conduit through a wiring access entry and attach the conduit fitting to the panel. Strip 0.52 (1.5 cm) of insulation from the end of each incoming wire. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 40 8. Replace the terminal block cover. 9. If an emergency power-off (disconnect) switch is required by local codes, see “Remote Emergency Power-Off” on page 36 to install the REPO switch before powering on the UPS. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 41 The UPS is now in Normal mode and supplying power to your equipment. NOTE The batteries charge to 90% capacity in approximately 3 hours. However, it is recommended that the batteries charge for 24 hours after installation or long-term storage. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 42: Remote Emergency Power-Off

    Installation Remote Emergency Power-Off The Powerware 9125 includes a REPO port that allows power to be switched off at the UPS output receptacles from a customer-supplied switch in a remote location. The REPO feature shuts down the protected equipment immediately and does not follow the orderly shutdown procedure initiated by any power management software.
  • Page 43 UPS by pressing the On button. 7. Activate the external REPO switch to test the REPO function. 8. De-activate the external REPO switch and restart the UPS. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 44: Ups Rear Panels

    Installation UPS Rear Panels This section shows the rear panels of the Powerware 9125 models. REPO Port Battery Connector Communication Port Fuse Holder Network X-Slot Transient Protector Two 5-20 Receptacles Circuit Protector Two 5-15 Receptacles 5-30 Receptacle Power Cord with 5-30P Figure 22.
  • Page 45 Figure 25. 2500/3000 VA, 208–240V Hardwired Rear Panel REPO Port Terminal Block Communication Port Network X-Slot Transient Protector Battery Connector with Cover Figure 26. 2500/3000 VA, 230V Hardwired Rear Panel Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 46 Installation Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 47: Operation

    If you do not unplug or remove utility power from the UPS, it remains in Standby mode. Pressing the Off button while the UPS is in Battery mode causes the UPS to shut down immediately. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 48: Initiating The Self-Test

    If the UPS finds a problem, an LED indicates where the problem is. For more information, see “Troubleshooting” on page 67. Operating Modes Powerware 9125’s front panel indicates the UPS status through the UPS indicators. Figure 27 shows the UPS front panel indicators and controls. Normal Mode Indicator...

  • Page 49: Normal Mode

    10%. Each LED represents 1/4 of a full load rating. When all of the bar graph indicators are illuminated and the indicator flashes, power requirements exceed UPS capacity; see page 69 for more information. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 50: Battery Mode

    Once these warnings are indicated, immediately complete and save your work to prevent data loss and similar difficulties. When utility power is restored after the UPS shuts down, the UPS automatically restarts. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 51: Bypass Mode

    If the UPS is on battery for approximately five minutes and supporting a small electrical load (ˆ 10%), the UPS shuts down the load. This feature conserves battery power. To enable this feature, contact your service representative. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 52 Operation Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 53: Configuration

    If you press the On button and nothing happens, the UPS is still in Operation mode. Repeat Step 1 for one beep ONLY to enter Configuration mode, and then perform Step 2. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 54 Configuration and Operation mode. Test/Alarm On Button Reset Button Press the On button to scroll to the next option. Figure 30. Using the Configuration Mode Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 55 220V for EU and EUH models and 208V for E and EH models are also available. Contact the help desk at one of the telephone numbers on page 70 for assistance. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 56 Configuration Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 57: Additional Ups Features

    : Load segments X-Slot Cards X-Slot cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The Powerware 9125 is factory-installed with a Single-Port card and is compatible with any X-Slot card, including: : Multi-Server Card - has six serial communication ports that can communicate with UPSs, terminals, computers, and modems.

  • Page 58: Single-Port Card

    To external device (tied to Pin 4) PnP from external device (default) or In / Out On Bypass relay contact (jumper-selectable) AC Fail AC Fail relay contact Power Source +V (8 to 24 volts DC power) Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 59 2. Move the J3 jumper to the AS/400 position to enable the On-Bypass relay as shown in Figure 34. On-Bypass On-Bypass Disabled Enabled NORM AS/400 On-Bypass Relay Jumper (J3) Figure 34. On-Bypass Relay Jumper Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 60: Network Transient Protector

    1. Connect the input connector of the equipment you are protecting to the jack labeled IN. 2. Connect the network or telephone cable (low voltage units only) to the jack labeled OUT. Figure 35. Network Transient Protector Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 61: Load Segments

    Figure 37. Load Segment 1 Load Segment 2 Figure 36. UPS Load Segments for 120V Models Load Segment 1 Load Segment 2 Figure 37. UPS Load Segments for 208V/230V Models Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 62 Additional UPS Features Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 63: Ups Maintenance

    After the five-second test is complete, the indicator should turn off (it may take a few seconds to turn off). If the indicator stays on, contact your service representative to order new batteries. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 64: Replacing Batteries

    5. Replace the EBM. See “Recycling the Used Battery” on page 62 for proper disposal. 6. Reinstall the pedestals if removed in Step 3. 7. Reinstall the EBM brackets if removed in Step 2. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 65 EBM cable into the battery connector on the first EBM. Attach the fixed cover plate to the EBM cable. Brackets EBM Battery Connectors UPS Battery Connector EBM Cables Figure 38. EBM Connections (120V Model Shown) Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 66: How To Replace Internal Batteries

    NOTE DO NOT attempt to open the left side. 2. Push down and unsnap the LED panel. 3. Disconnect the battery cable from the UPS and cut the battery cable wire tie. Battery Cable LED Panel Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 67: Testing New Batteries

    (it may take a few seconds to turn off). If the indicator stays on, check the battery connections. Call your service representative if the problem persists. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 68: Recycling The Used Battery

    Do not discard the UPS or the UPS batteries in the trash. This product contains sealed, lead-acid batteries and must be disposed of properly. For more information, contact your local recycling or hazardous waste center. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 69: Specifications

    C H A P T E R 8 PECIFICATIONS This section provides the following specifications for the Powerware 9125 models: : Electrical input and output : Environmental and safety : Weights and dimensions : Battery Table 4. Model Specifications Power Levels...
  • Page 70 UL 1778, UL 497A; IEC 60950; EN 50091-1-1; NOM-019-SCFI CSA C22.2, No. 107.1, 107.2; NOM-019-SCFI Agency Markings UL, cUL, NOM-NYCE CE, TUV-GS EMC (Class A) FCC Part 15, ICES-003 EN 50091-2, IEC 62040-2 Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 71 Batteries 2500 VA/1750W 7/16 28/57 48/90 68/150 88/200 3000 VA/2100W 5/13 25/55 38/72 54/120 70/160 NOTE Battery times are approximate and vary depending on the load configuration and battery charge. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 72 Specifications Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 73: Troubleshooting

    Figure 39. Alarm Indicators Silencing an Audible Alarm To silence the alarm for an existing fault, press the button. If UPS status changes, the alarm beeps, overriding the previous alarm silencing. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 74 Three minutes or less of battery power remains (depending on load configuration and battery charge). Prepare for a shutdown. Save your work and turn off your Warning - Low Battery equipment. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
  • Page 75 5 seconds until all LEDs are off and restart the UPS. defective. If the overload condition persists (101–110% for 2 minutes Overload or 111–150% for 30 seconds), the UPS automatically shuts Continuous audible alarm down. Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...

  • Page 76: Service And Support

    A replacement or repair unit will be shipped, freight prepaid for all warrantied units. NOTE For critical applications, immediate replacement may be available. Call the for the dealer or distributor nearest you. Help Desk Powerware 9125 User’s Guide (2500–3000 VA) Rev B www.powerware.com ®...
