Item
1
2
3
4
5
6
7
8
9
92 Configuring HPE Synergy
Description
Navigation menu - Breadcrumb navigation menu.
Frame Health - Provides the overall frame health status.
Statuses include:
• OK
• Warning
• Critical
Information - Provides detailed frame information including name, serial
number, power information, ambient temperature, maintenance console status,
and the number of active HPE Synergy Console sessions.
Maintenance Console - Indicates whether FLM Maintenance Console access is
enabled or disabled. Indicates whether a maintenance console password has
been set (configured) in HPE OneView to further restrict unauthorized access.
Frame Management Network - Provides the network address associated with
the Active frame link module. This network address is used to manage the frame
and is independent of the frame link module-specific addresses.
NOTE: When adding remote frames (enclosures) to HPE OneView, use this link
local IPv6 address.
Frame Link Module Ports - Displays the frame link module MGMT and LINK
port information for the Active and Standby frame link modules.
Thermal Subsystem - Displays the frame ambient temperature and detailed fan
speed data including which device is driving the fan speed for each fan.
FLM Certificates - Displays the frame link module certificates and public keys.
Frame rear view - Displays the components installed in the rear of the frame
and the health status of each component. Each component can be clicked to
view individual component health and information screens.
Health statuses include:
• Green: OK
• Yellow: Warning
• Red: Critical
Table Continued
