HPE Synergy 12000 Frame Setup And Installation Manual page 27

Item Description
3 KVM port
4 Appliance port 1
connectivity LED
5 Appliance port 2
connectivity LED
6 Appliance port 2
7 Appliance port 1
8 UID button
9 USB adapter thumbscrew
connection
Function
NOTE: Connection to the KVM port requires an HPE Synergy 4-Port Frame Link
Module USB Adapter.
NOTE: Supports storage devices that are USB 2.0 compatible.
When an HPE Synergy 4-Port Frame Link Module USB Adapter is installed, the
HPE Synergy 4-Port Frame Link Module:
• Allows connection to the frame using a supported USB device.
Devices include a keyboard or mouse for connecting to the HPE Synergy
Console. To connect multiple devices, a USB hub (not included) is required.
• Allows connection to the frame using a monitor device or an active monitor
port adapter.
Used for performing a USB recovery frame link module firmware update.
Reserved for future use.
Reserved for future use.
Reserved for future use.
Reserved for future use.
Toggles the UID LED on or off.
• Solid blue = Activated
• Off = Deactivated
• Flashing blue = Firmware upgrade is in progress on the frame link module.
Do not remove either frame link module while the UID LED is flashing.
For securing an HPE Synergy 4-Port Frame Link Module USB Adapter to the HPE
Synergy 4-Port Frame Link Module.
Table Continued
Component and LED identification 27
