HPE StoreEver MSL4048

Tape Library Chassis

repackaging instructions

Development LP

Part Number: AG320-96017

Published: October 2018

Edition: 3

CAUTION:

Not following this procedure can cause damage to

the chassis during shipment and may void the

warranty.

1 Replacing the shipping lock

When possible, power off the chassis from the front

panel so the robot will be in the correct location to be

restrained by the shipping lock. 1) Remove the shipping

lock from its storage position on the back of the chassis.

2) If possible, place the shipping lock in the shipping

position on top of the chassis. 3) Tape the shipping lock

to the chassis to keep it in place during shipping.

If you removed drive bay covers from the new chassis,

attach them to the chassis you are returning.

From the back of the chassis, locate an uncovered drive

bay. Use Phillips screws to attach the drive bay covers to

the chassis.

Insert one foam block into each pair of magazine bays.

Page 1

Table of Contents

Do you have a question about the StoreEver MSL4048 and is the answer not in the manual?

Page 1 1 Replacing the shipping lock HPE StoreEver MSL4048 When possible, power off the chassis from the front panel so the robot will be in the correct location to be restrained by the shipping lock. 1) Remove the shipping Tape Library Chassis lock from its storage position on the back of the chassis.
Page 2 Wrap the foam sheet around the chassis. 4 Packing the box Place the foam pieces and chassis in the box in the order shown. Page 2...
