Item Name
1 HPE Synergy 12000 Frame
2 Front panel
3 Appliance module blank
4 Appliance module
5 Compute module blank
6 Full-height module
7 Half-height module
8 Power supply blank
9 Hot-plug power supply
10 Fan
11 Frame link module
12 Interconnect blank
13 Interconnect module
14 Lift handles (optional)
15 Removable device bay shelves
1
1
1
1
1
2
3
3
Description
The frame for installing HPE Synergy
components.
The front panel ports of the frame for KVM
connection.
A mandatory insert installed in any unused
appliance module bay.
A hardware appliance for embedded
management.
A mandatory insert installed in any unused
compute module bay.
The full-height compute module.
The half-height compute module.
A mandatory insert installed in any unused
power supply bay.
The power supply for the frame.
A fan used to cool the components installed
in the frame.
The frame link module auto-discovers
resources in the frame, has a redundant
option, and provides links for scaling of
frames.
A mandatory insert installed in any unused
interconnect bay.
Any of several fabric or networking
components, such as switches or
interconnect link modules, that enable
networking communication.
The lift handles can be used to lift a frame
into or out of a rack.
The removable device bay shelves can be
used to partition the device bays for full or
half-height components.
