HPE Synergy 12000 Frame Setup And Installation Manual page 28

Item Description
10 Health LED
11 LINK port
12 MGMT port
28 Component and LED identification
Function
Provides the health status of the frame link module.
• Solid green = Normal operation
• Flashing amber = Warning
• Flashing red = Critical error
If the Health LED indicates a warning or a critical error, connect to HPE
OneView or to the HPE Synergy Console for more information and
troubleshooting assistance.
SFP+ connector that provides the following functions:
IMPORTANT: Use supported SFP+ 10GbE DAC cables or transceivers for
LINK port connections. For more information, see the product QuickSpecs
on the Hewlett Packard Enterprise website.
• Provides high availability management network connectivity between:
◦ LINK ports on two frame link modules in the same frame for a single frame
configuration
◦
Frame link modules in different frames as part of a management network
ring in a multiframe configuration
• Provides management ring (frame link topology) connectivity for automatic
frame discovery by HPE OneView.
SFP+ connector that provides the following functions:
IMPORTANT: Use supported SFP+ DAC cables or transceivers for MGMT
port connections. For more information, see the product QuickSpecs on the
Hewlett Packard Enterprise website.
IMPORTANT: The transceiver or cable used must match the port speed of
the switch used for management network connectivity.
• Provides a management uplink to the management network.
• 10GbE or 1GbE based on the cable or transceiver used.
