HPE Synergy 12000 Frame Setup And Installation Manual page 82

CAUTION: To prevent improper cooling and thermal damage, do not operate the frame unless all bays are
populated with either a component or a blank.
Installing the DC power grounding kit (no bracket)
For clarity, the rack is not shown in the images of this procedure.
Prerequisites
The following tools are required to complete this procedure:
• T-30 Torx screwdriver
• 8 mm socket wrench
Procedure
1. Using one hex thread-forming screw and lock washer, connect the grounding cable to the frame.
Tighten the screw to 15lb-in of torque.
2. Using the screw supplied with the rack, connect the grounding cable to the grounding rail.
82 Installation
