1.2 Typical System Installation
Figure 1-2
installed as part of a public address system.
Optional 011471 IP66 Analog Horn
(sold separately)
Operations Guide
illustrates how the InformaCast Enabled Loudspeaker Amplifier (PoE) is normally
Figure 1-2. Typical Installation
802.3at PoE Ethernet Switch
InformaCast Enabled Loudspeaker
Amplifier (PoE)
High Power PoE Injector in Box
931277I
SIP Server
VoIP Phone
Product Overview
Typical System Installation
CyberData Corporation
2
