2.2.9 Connecting the Optional 011288 Auxiliary RGB Strobe

1. Remove the mounting screw to remove the cover plate. See
2. Remove the hole plug and grommet. See
3. Slide the cover plate through the slot on the cable grommet. See
4. Feed the strobe cable through an available gland near the bottom of the enclosure.
5. Connect the strobe cable to the STROBE IN connection (J9) (see
6. Install the mounting screw to secure the cover plate. See
Figure 2-14. Connecting the Optional 011288 Auxiliary RGB Strobe
Paging Amplifier
Mounting Screw
Network Cable
to Network Port
Network Cable
through Cable Gland
Operations Guide
and to J1 of the board of the optional 011288 Auxiliary RGB Strobe (sold separately).
Cover
Screw
Remove Hole Plug
and Grommet
Cover
Plate
STROBE IN
Paging Amplifier
Installing the InformaCast Enabled Loudspeaker Amplifier (PoE)
InformaCast Enabled Loudspeaker Amplifier (PoE) Setup
Figure 2-14.
Slide Cable Grommet
into Cover Plate Slot
to
STROBE IN
Paging Amplifier
Mounting Screw
MIC IN
931277I
Figure 2-14.
Figure 2-14.
Figure 2-14 and
Figure 2-14.
Backplate
Cable
Exit Slot
to
J1
J1
RGB Strobe
Cable
Exit Slot
CyberData Corporation
23
Figure 2-15)
