1.2 Typical System Installation

Figure 1-2
installed as part of a public address system.
Operations Guide
illustrates how the Singlewire InformaCast Loudspeaker Amplifier (PoE) is normally
Figure 1-2. Typical Installation
Compliant Non-PoE Ethernet Switch
Singlewire InformaCast
Loudspeaker Amplifier
High Power PoE Injector in Box
Warning
Electrical Hazard:
enclosure is not rated for any AC voltages.
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
VoIP Phone
The Singlewire InformaCast Loudspeaker Amplifier (PoE)
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
931277B
Product Overview
Typical System Installation
SIP Server
