1.2 Typical System Installation
Figure 1-2
system.
The IP66 Analog Horn
(part #011471) must be
purchased separately.
Operations Guide
illustrates how the SIP Paging Amplifier is normally installed as part of a public address
Figure 1-2. Typical Installation
Compliant PoE Ethernet Switch
SIP Paging Amplifier
931156K
IP-PBX Server
VoIP Phone
Product Overview
Typical System Installation
CyberData Corporation
2
