Installing the InformaCast Enabled Loudspeaker Amplifier (PoE)
14
InformaCast Enabled Loudspeaker Amplifier (PoE) Setup
2.2.3 Assembling the Cable Gland
Assemble the cable gland as shown in
Figure
2-3.
Figure 2-3. Assembling the Cable Gland
Washer
Nut
Coupling
NEMA
Enclosure
Bushing
End Cap
Hole Plug
Operations Guide
931277I
CyberData Corporation
