1.2 Typical System Installation

Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Figure 1-2 illustrates how the SIP Loudspeaker Amplifier (PoE) is normally installed as part of a
public address system.
Figure 1-2. Typical Installation
Compliant Non-PoE Ethernet Switch
Loudspeaker Amplifier
Warning
Electrical Hazard:
for any AC voltages.
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
VoIP Phone
The SIP Loudspeaker Amplifier (PoE) enclosure is not rated
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
