1.2 Typical System Installation

Figure 1-2
address system.
Loudspeaker Amplifier
Operations Guide
illustrates how the VoIP V2 Loudspeaker Amplifier is normally installed as part of a public
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1
PoE Injector
(High Power Mode with Injector)
Loudspeaker Amplifier
Warning
Electrical Hazard:
any AC voltages.
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
2 3 4 5 6
VoIP Phone
The VoIP V2 Loudspeaker Amplifier enclosure is not rated for
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
930362L
Product Overview
Typical System Installation
SIP Server
CyberData Corporation
2
