2.3.10 Configure the Sensor Page Parameters
The door sensor (pins 1 and 2) on the terminal block can be used to monitor a door's open or closed
state. There is an option on the
The door sensor alarm will be activated when the
been met.
Each sensor can trigger up to five different actions:
•
•
•
•
•
Note
1. Click Sensor menu button to open the
Operations Guide
Flash the LED until the sensor is deactivated (roughly 10 times/second)
Activate the relay until the sensor is deactivated
Loop an audio file out of the speaker until the sensor is deactivated
Call an extension and establish two way audio
Call an extension and play a pre-recorded audio file
Calling a preset extension can be set up as a point-to-point call, but currently can't send
delayed DTMF tones.
Installing the InformaCast Enabled Loudspeaker Amplifier (PoE)
InformaCast Enabled Loudspeaker Amplifier (PoE) Setup
Sensor Page to trigger on an open or short condition on these pins.
Sensor Timeout (in seconds)
Sensor Page (Figure
931277I
parameter has
2-38).
