Requirements

System require- (1)
ments and mini-
mum equipment
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Mechanical re- The following mechanical requirements must be met in order to achieve a stable and re-
quirements
producible TWIN welding process:
-
-
-
Electrical Re- -
quirements -
Software require- -
ments -
-
TWIN welding torch
MTB 2x500 A PA or PB
+ TWIN Basic Kit xx°
CrashBox
TWIN hosepack
MHP 2x500 A W/FSC
+ TWIN Basic Kit (depending on material and wire diameter)
TWIN wirefeeder
WF 30i R /TWIN
Wirefeeder holder
WF MOUNTING TWIN
Interconnecting hosepacks
1 x HP 95i CON /W /xx m
+
1 x HP 95i CON /G /xx m
2 x wirefeeding hose (max. 3 m) or Fronius PowerLiner (max. 10 m)
2 x power source
TPS 400i Pulse / 500i Pulse / 600i Pulse
or
TPS 400i / 500i / 600i with Welding Package Pulse
+ firmware official_TPSi_2.2.3-20789.15069.ffw and above
Cooling unit
CU 2000i Pro/MC (2-part)
TWIN Controller
RI FB Pro/i TWIN Controller
+ firmware official_robpro-1.4.1-xx-svn6108_official
2 x grounding cable
Precise welding torch guidance for robots or single-purpose machines (e.g. longitudi-
nal chassis)
Exact weld preparation
Low component tolerances
Cables of the welding circuit laid correctly
The max. inductance in the welding circuit must not exceed 35 µH.
Software version at least 2.2.3-20789.15069 or above
Both power sources must have the same software status.
The IP addresses must be set correctly on the power sources.
