Interconnecting hosepack

Interconnecting
Hosepack—Con-
nections
W = water-cooled interconnecting hosepack
G = gas-cooled interconnecting hosepack
60
(1)
(2)
W
(3)
(4)
(1)
G
(3)
(4)
(1) SpeedNet cable
(2) Coolant hoses
(2)
(3) Protective gas shield hose
(4) Power cable
1
(3)
(1)
(4)
2
(3)
(1)
(4)
