PMC TWIN / PMC
TWIN
Welding current time curves and schematic representation of the material transition
P = phase shift
Time coordination of the power sources
The PMC processes of the two process lines are synchronized with one another. This
guarantees a stable, consistent tandem welding process.
The relative position of the pulse/droplet detachment is stored in the characteristic but can
also be freely selected.
Significantly different outputs at lead and trail wire electrode
The TPS/i TWIN welding system enables significantly different outputs or wire speeds to
be used, even during synchronized PMC tandem processes.
A significantly higher output is usually selected at the lead wire electrode than at the trail
wire electrode.
This results in:
-
-
-
-
-
-
NOTE!
The TWIN process PMC TWIN/PMC TWIN should generally be used for all welding
applications.
I (A)
I
I
L
T
I
> I
L
T
targeted heat input
the cold parent material melts well
exact recording of the root pass
trail wire electrode fills up the weld pool
extension of the gas release time (reduced proneness to porosity)
high welding speed
P
t (s)
45
