Fronius TPS/i Robotics TWIN Push Operating Instructions Manual page 99

α = 8.0°
SO [mm] L1 [mm] s [mm]
15 60.91 13.65
16 61.90 13.65
17 62.90 13.65
18 63.90 13.65
19 64.90 13.65
20 65.89 13.65
21 66.89 13.65
22 67.89 13.65
23 68.89 13.65
α = 4.0°
SO [mm] L1 [mm] s [mm]
15 61.24 17.32
16 62.24 17.32
17 63.24 17.32
18 64.24 17.32
19 65.24 17.32
20 66.23 17.32
21 67.23 17.32
22 68.23 17.32
23 69.23 17.32
β = 30° / PB & PA
x [mm] L [mm] H [mm]
11.55 327.44 82.18
11.42 328.30 82.67
11.28 329.17 83.17
11.14 330.03 83.67
11.00 330.89 84.17
10.86 331.76 84.67
10.72 332.62 85.17
10.58 333.49 85.67
10.44 334.35 86.17
β = 30° / PB & PA
x [mm] L [mm] H [mm]
16.27 327.73 82.34
16.20 328.59 82.84
16.14 329.46 83.34
16.07 330.32 83.84
16.00 331.19 84.34
15.93 332.05 84.84
15.86 332.92 85.34
15.79 333.78 85.84
15.72 334.65 86.34
β = 45° / PB & PA
L [mm] H [mm]
337.22 136.93
338.08 137.43
338.95 137.92
339.81 138.42
340.68 138.92
341.54 139.42
342.40 139.92
342.27 140.42
344.13 140.92
β = 45° / PB & PA
L [mm] H [mm]
337.51 137.09
338.37 137.59
339.24 138.09
340.10 138.59
340.97 139.09
341.83 139.59
342.70 140.09
343.57 140.59
344.43 141.09
