Function of the Gas-test button
Gas-Test, Wire-
Return and Wire After pressing the gas-test button, gas is released for 30 s. Pressing the button again will
Threading But- end the process prematurely.
tons
Wire-return button
There are two options available for retracting the wire electrode:
Option 1
Withdraw wire electrode at the preset wire return speed:
-
-
-
Option 2
Withdraw wire electrode in 1 mm steps (0.039 in. steps)
-
NOTE!
Only retract the wire electrode a small amount at a time, to avoid the wire electrode
becoming entangled on the wirespool during retraction.
NOTE!
If there is a ground earth connection with the contact tip, before the wire-return but-
ton is pressed, the wire electrode is retracted by pressing the wire-return button un-
til the wire electrode is short-circuit-free—however, this must not exceed 10 mm
(0.39 in.) each time the button is pressed.
If the wire electrode needs to be retracted further, press the wire-return button again.
4-roller drive 2
Clamping lever 2
for adjusting the contact pressure of the feed rollers
Protective cover of the 4-roller drive 2
Welding torch clamping lever 2
Cover
Press and hold the wire-return button
After pressing the wire-return button, the wire electrode is retracted by 1 mm (0.039
in.)
After a brief pause, the wirefeeder continues retracting the wire electrode—if the wire-
return button is kept pressed down, then the speed increases with each further second
by 10 m/min (393.70 ipm) until the preset wire-return speed is reached
Always press (touch) the wire-return button for less than 1 second
