Operation and setting
N. freq
Use this menu option to select the nominal frequency of the system to be mo-
nitored. You may select 50, 60 or 400 Hz. Factory setting = 50 Hz.
System
Use this menu option to select the type of the distribution system to be moni-
tored.
You may select:
DC = DC system
 
AC = single-phase AC system
 
3 AC = three-phase AC system
 
Factory setting = AC.
6.7.2

Channel

The following parameters have an effect on the device the BMS address and
measuring channel of which is being displayed. Set the respective address
and channel in order to select the appropriate device.
IRDH575_D00089_05_M_XXEN/01.2020
64
