Serial interfaces
BMS bus address ranges
Addresses*
0
1
...
1 30
...
30
1
...
2 30
...
31 60
...
1 90
...
61 90
...
111 119
...
121 150
IRDH575_D00089_05_M_XXEN/01.2020
Device
There is no device with address 0 !
Information sent to BMS address 0 applies
to all devices connected to the BMS bus
(broadcast)
PRC1470 Control and indicating device
IRDH275B Insulation monitoring device
/375B/575
...
Protocol converter
FTC470
...
Insulation fault evaluators (localisation)
EDS47
SMO480 Signal converter relay
...
Insulation fault evaluator (localisation
EDS4 E
2
...
Insulation fault evaluators (localisation)
EDS46
...
/ 49
...
Insulation fault evaluators (localisation)
EDS4 E
PGH47x Insulation fault test device
PGH47xE Insulation fault test device
*Malfunctions due to wrong address assignment!
Assigning wrong addresses to external devices may cause
malfunctions. Assign the addresses in a way that there are
no gaps of more than five subsequent addresses (1...30,
31...60, 61...90, 111...119 und 121...151).
Meaning
