9.3 Characteristic curves

9.3.1 Characteristic curves of the ISOMETER®
ISOMETER® response times in relation to system leakage capaci-
tances of:
= 1...500 µF
C
e
= 20...575 V (Version B1) / 50 Hz
U
n
= 340...760 V (Version B2) / 50 Hz
U
n
1000
t
[s]
an
100
10
1
1
IRDH575_D00089_05_M_XXEN/01.2020
10
C
[µF]
e
100
≤ Ω
10 M
R
F
Ω
≥
0 k
