Table 5-3 Linux Devices Memory Map - SMART Embedded Computing MVME2502 Installation And Use Manual

Table 5-3
Device Memory Range
ecm (Error Correction Module) CCSR
Memory Controller CCSR
I2C1 CCSR
I2C2 CCSR
UART0 CCSR
UART1CCSR
ELBC CCSR
SPI CCSR
PCIE3 CCSR
PCIE2 CCSR
PCIE1CCSR
DMA2 CCSR
GPIO CCSR
L2 Cache CCSR
DMA1 CCSR
USB CCSR
ETSEC1 CCSR
ETSEC2 CCSR
ETSEC3 CCSR
SDHCI CCSR
Crypto CCSR
msi CCSR
mpic CCSR
Global Utilities CCSR
L2 Cache Mem
MVME2502 Installation and Use (6806800R96G)
Linux Devices Memory Map (continued)
Memory Maps and Registers
Memory Area
0xffe01000 0xffe01fff
0xffe02000 0xffe02fff
0xffe03000 0xffe030ff
0xffe03100 0xffe031ff
0xffe04500 0xffe045ff
0xffe04600 0xffe046ff
0xffe05000 0xffe05fff
0xffe07000 0xffe07fff
0xffe08000 0xffe08fff
0xffe09000 0xffe09fff
0xffe0a000 0xffe0afff
0xffe0c100 0xffe0c303
0xffe0fc00 0xffe0fcff
0xffe20000 0xffe20fff
0xffe21100 0xffe21303
0xffe22000 0xffe22fff
0xffe24000 0xffe24fff
0xffe25000 0xffe25fff
0xffe26000 0xffe26fff
0xffe2e000 0xffe2efff
0xffe30000 0xffe3ffff
0xffe41600 0xffe4167f
0xffe40000 0xffe7ffff
0xffee0000 0xffee0fff
0xf0f80000 0xf0ffffff
Size
4KB
4KB
256B
256B
256B
256B
4KB
4KB
4KB
4KB
4KB
516B
256B
4KB
516B
4KB
4KB
4KB
4KB
4KB
64KB
128B
256KB
4KB
512KB
97
