3.4

Connectors

This section describes the pin assignments and signals for the connectors on the
MVME2502 board.
3.4.1

Front Panel Connectors

The following connectors are found on the outside of the MVME2502 board. These
connectors are divided between the front panel connectors and the backplane connectors.
The front panel connectors include the J1 and the J5 connectors. The backplane
connectors include the P1 and the P2 connectors.
3.4.1.1 RJ-45 with Integrated Magnetics (J1)
The MVME2502 uses an X2 RJ-45.
Table 3-3
Pin Name
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
D1A
D2A
D3A
D4A
1B
2B
3B
MVME2502 Installation and Use (6806800R96G)
Front Panel Tri-Speed Ethernet Connector (J1)
Signal Description
GND
NC
Port A TRD3 -
Port A TRD3 +
Port A TRD2 -
Port A TRD2 +
Port A TRD1 -
Port A TRD1 +
Port A TRD0 -
Port A TRD0 +
Port A Green LED1 Anode / Yellow LED1 Cathode
Port A Yellow LED1 Anode / Green LED1 Cathode
Port A Green LED2 Anode / Yellow LED2 Cathode
Port A Yellow LED2 Anode / Green LED2 Cathode
GND
NC
Port B TRD3 -
