Controls, LEDs, and Connectors
Table 3-7
Pin
23
24
25
26
27
28
29
30
31
32
3.4.2

On-board Connectors

3.4.2.1

SATA Connector (J3)

The on-board customized SATA connector is compatible with SATA kit, namely
VME-64GBSSDKIT and iVME7210-MNTKIT.
Table 3-8
Pin
1
2
3
4
5
6
7
8
9
56
VMEbus P2 Connector (continued)
Row A Row B
PMC IO 46 DATA 24
PMC IO 48 DATA 25
PMC IO 50 DATA 26
PMC IO 52 DATA 27
PMC IO 54 DATA 28
PMC IO 56 DATA 29
PMC IO 58 DATA 30
PMC IO 60 DATA 31
PMC IO 62 GND
PMC IO 64 +5V
Custom SATA Connector (J3)
Signal Description
GND
GND
NC
SATA TX +
NC
SATA TX -
GND
GND
GND
Row C Row D
PMC IO 45 GE4_2 -
PMC IO 47 GE4_2+
PMC IO 49 GND
PMC IO 51 GE4_1 -
PMC IO 53 GE4_1 +
PMC IO 55 GND
PMC IO 57 GE4_0 -
PMC IO 59 GE4_0 +
PMC IO 61 GND
PMC IO 63 +5V
Pin Signal Description
21 GND
22 SATA POWER ENABLE
23 NC
24 SATA DETECT
25 NC
26 GND
27 NC
28 GND
29 GND
MVME2502 Installation and Use (6806800R96G)
Controls, LEDs, and Connectors
Row Z
Serial 3 RTS
GND
Serial 4 RX
GND
Serial 4 TX
GND
Serial 4 CTS
GND
Serial 4 RTS
GND
