Front Panel
The following components are found on the MVME2502 ENP1 and ENP2 front panel.
Figure 3-3 Front Panel LEDs, Connectors and Switches
Serial Port
USB
ETH 1
ETH 2
MVME2502 Installation and Use (6806800R96G)
PMC/XMC 2
PMC/XMC 1
USER 1
Reset Switch
FAIL
SPEED
ACT
SPEED
ACT
Controls, LEDs, and Connectors
47
