Table 7-1
CONFIG
SDHC Card
30 Detect
Polarity
RAPID
31
System Size
7.3

Interrupt Controller

The MVME2502 uses the MPC8548E integrated programmable interrupt controller (PIC)
to manage locally generated interrupts. Currently defined external interrupting devices,
interrupt assignments, along with corresponding edge/levels, and polarities are shown in
the following table.
Table 7-2
Interrupt Line
IRQ0
IRQ1
IRQ2
IRQ3
IRQ4
IRQ5
IRQ6
IRQ7/ GPIO0
IRQ8/ GPIO1
IRQ9/ GPIO2
IRQ10// GPIO3
MVME2502 Installation and Use (6806800R96G)
POR Configuration Settings (continued)
CONFIG PINS
TSEC2_TXD_5
MVME2502 Interrupt List
Interrupt Usage
(Schematic)
None
QUART_IRQ1
QUART_IRQ2
QUART_IRQ3
Temperature
Interrupt
Ethernet 1
Ethernet 3
Ethernet 2
RTC (Real Time
Clock)
CPLD Interrupt
CPLD Interrupt
CONFIG SELECTION
1 Not Inverted
Default
Interface to CPU Description
Reserved for VME interrupt
LBC RTB Quart Interrupt
LBC RTB Quart Interrupt
LBC RTB Quart Interrupt
Two on-board Thermal Sensors:
I2C one is for CPU temp and the other
is for board temp
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
12C DS1337 INT_A
LBC NMI and 3 Tick Timer Interrupts
LBC Not used
Programming Model
REMARKS
RapidIO is not used
129
