Table 3-1
Label
FAIL
GENET1
SPEED
GENET1
ACT
GENET2
SPEED
GENET2
ACT
MVME2502 Installation and Use (6806800R96G)
Front Panel LEDs (continued)
Function Location
Board Fail Front panel
Front panel
TSEC1
Integrated
Link/Speed
RJ-45 LED
Front panel
TSEC1
Integrated
Activity
RJ-45 LED
Front panel
TSEC2 Integrated
Link/Speed RJ-45 LED
(Left)
Front panel
TSEC2
Integrated
Activity
RJ-45 LED
Controls, LEDs, and Connectors
Color Description
Normal operation after successful
Off
firmware boot.
Red
One or more on-board power rails
has failed and the board has
shutdown to protect the hardware.
Normal during power up, during
hardware reset (such as a front
panel reset). May be asserted by the
BDFAIL bit in the Tsi148 VSTAT
register.
Off No link
Amber 10/100BASE-T operation
Green 1000 BASE-T operation
Off No activity
Blinking Green Activity proportional to bandwidth
utilization
Off No link
Amber 10/100BASE-T operation
Green 1000BASE-T operation
Off No activity
Blinking Green Activity proportional to bandwidth
utilization
