I 2 C Bus Device Addressing - SMART Embedded Computing MVME2502 Installation And Use Manual

Programming Model
Table 7-2
Interrupt Line
IRQ11// GPIO4
2
7.4 I C Bus Device Addressing
The following table contains the I
device address.
Table 7-3
2
I C Bus Address
0x50
0x4C
0x68
0x54
0x52
0x53
0x55
0x56
1. This is a dual address serial EEPROM.
2. The RTM Bus address is manually changed through the S1 Switch on RTM. The
default switch configuration will set the address to 0x55. Make sure that the address is
unique to the RTM Bus address when setting the switch.
3. The address of the XMC EEPROM is configured through Geographic Address resistor
on- board.
130
MVME2502 Interrupt List (continued)
Interrupt Usage
(Schematic)
QUART_IRQ0
2
C devices used for the MVME2502 and its assigned
2
I C Bus Device Addressing
Device Function
SPD
ADT 7461 Temperature Sensor
DS 1375 real-time clock
VPD
User configuration
User configuration
RTM EEPROM
XMC EEPROM
Interface to CPU Description
LBC RTB Quart Interrupt
Size
256 x 8
N/A
N/A
8192 x 8
65536 x 8
65536 x 8
8192 X 8
N/A
MVME2502 Installation and Use (6806800R96G)
Programming Model
Notes
1
1
1
1, 2
3
