Controls, LEDs, and Connectors
Table 3-6
Pin
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
54
VMEbus P1 Connector (continued)
Row A Row B
GND BGOUT3
DS1 BR0
DS0 BR1
WRITE BR2
GND BR3
DTACK AM 0
GND AM 1
AS AM 2
GND AM 3
IACK GND
IACKIN NC
IACKOUT NC
AM 4 GND
ADD 7 IRQ7
ADD 6 IRQ6
ADD 5 IRQ5
ADD 4 IRQ4
ADD 3 IRQ3
ADD 2 IRQ2
ADD 1 IRQ1
-12V NC
+5V +5V
Row C Row D
BERR GA1
SYSRESET +3.3V (not used)
LWORD GA2
AM 5 +3.3V (not used)
ADD 23 GA3
ADD 24 +3.3V (not used)
ADD 25 GA4
ADD 26 +3.3V (not used)
ADD 27 NC
ADD 28 +3.3V (not used)
ADD 29 NC
ADD 30 +3.3V (not used)
ADD 31 NC
ADD 32 +3.3V (not used)
ADD 33 NC
ADD 34 +3.3V (not used)
ADD 35 NC
ADD 36 +3.3V (not used)
ADD 37 NC
ADD 38 +3.3V (not used)
+12V +12V
+5V +5V
MVME2502 Installation and Use (6806800R96G)
Controls, LEDs, and Connectors
Row Z
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
NC
GND
