Usb Connector (J5); Vmebus P1 Connector; Table 3-5 Usb Connector (J5); Table 3-6 Vmebus P1 Connector - SMART Embedded Computing MVME2502 Installation And Use Manual

3.4.1.3

USB Connector (J5)

The MVME2502 uses upright USB receptacle mounted in the front panel.
Table 3-5
Pin Name
1
2
3
4
MTG
MTG
MTG
MTG
3.4.1.4

VMEBus P1 Connector

The VME P1 connector is a 160-pin DIN. The P1 connector provides power and VME
signals for 24-bit address and 16-bit data. The pin assignments for the P1 connector is as
follows:
Table 3-6
Pin
1
2
3
4
5
6
7
8
9
10
MVME2502 Installation and Use (6806800R96G)
USB Connector (J5)
VMEbus P1 Connector
Row A Row B
DATA 0 BBSY
DATA 1 BCLR
DATA 2 ACFAIL
DATA 3 BGIN0
DATA 4 BGOUT0
DATA 5 BGIN1
DATA 6 BGOUT1
DATA 7 BGIN2
GND BGOUT2
SYSCLK BGIN3
Controls, LEDs, and Connectors
Signal Description
+5V
Data -
Data +
GND
Mounting Ground
Mounting Ground
Mounting Ground
Mounting Ground
Row C
DATA 8
DATA 9
DATA 10
DATA 11
DATA 12
DATA 13
DATA 14
DATA 15
GND
SYSFAIL
Row D Row Z
+5V NC
GND GND
NC NC
NC GND
NC NC
NC GND
NC NC
NC GND
GAP NC
GA0 GND
