Controls, LEDs, and Connectors
Table 3-9
Pin
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
58
PMC J11/J111 Connector (continued)
Signal Description
NC
GND
NC
PCI CLK
GND
GND
GNT A
REQ A
+5V
+3.3V
AD 31
AD 28
AD 27
AD 25
GND
GND
CBE3
AD 22
AD 21
AD 19
+5V
+3.3V
AD 17
Controls, LEDs, and Connectors
Pin Signal Description
42 NC
43 PAR
44 GND
45 +3.3V
46 AD 15
47 AD 12
48 AD 11
49 AD 9
50 +5V
51 GND
52 CBE0
53 AD 6
54 AD 5
55 AD 4
56 GND
57 +3.3V
58 AD 3
59 AD 2
60 AD 1
61 AD 0
62 +5V
63 GND
64 REQ64
