Functional Description
4.2.7

USB Interface

The P2020 implements a USB 2.0 compliant serial interface engine. For more information,
see USB on page
4.2.8

DUART

The chipset provides two universal asynchronous receiver/transmitter (UART). Each UART
is clocked by the CCB clock and is compatible with PC16522D. As a full-duplex interface,
it provides 16-byte FIFO for both transmitter and receiver mode.
4.2.9

DMA Controller

The DMA controller transfers blocks of data between the various interfaces and functional
blocks of P2020 that are independent of the e500 cores. The P2020 DMA controller has
three high-speed DMA channels, all of which are capable of complex data movement and
advanced transaction chaining.
4.2.10

Enhanced Three-Speed Ethernet Controller (eTSEC)

The eTSEC controller of the device communicates to10Mbps, 100Mbps, and 1Gbps
Ethernet/IEE 802.3 networks, and devices featuring generic 8 to 16-bit FIFO ports. The
MVME2502 uses the eTSEC using the RGMII interface.
4.2.11

General Purpose I/O (GPIO)

The P2020 has a total of sixteen I/O ports. Four of these ports are used alternately as
external input interrupt. All sixteen ports have open drain capabilities.
The table below details the GPIO usage for the MVME2502:
Table 4-1
GPIO bit CPU Pin #
15
14
13
12
11
74
86.
P2020 GPIO Functions
Function
E24 Not connected
F24 Not connected
E23 Connected to pin R7 of the CPLD (unused input)
F23 Connected to pin M8 of the CPLD (unused input)
D24 Connected to pin M7 of the CPLD (unused input)
MVME2502 Installation and Use (6806800R96G)
