Table 3-12 Pmc J14 Connector - SMART Embedded Computing MVME2502 Installation And Use Manual

Table 3-11
Pin
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Table 3-12
Pin
1
2
3
4
5
6
7
8
9
10
MVME2502 Installation and Use (6806800R96G)
PMC J13/J333 Connector (continued)
Signal Description
AD 57
GND
+3.3V
AD 56
AD 55
AD 54
AD 53
GND
GND
GND
AD 51
AD 50
AD 49
GND
PMC J14 Connector
Signal Description
PMC IO 1
PMC IO 2
PMC IO 3
PMC IO 4
PMC IO 5
PMC IO 6
PMC IO 7
PMC IO 8
PMC IO 9
PMC IO 10
Controls, LEDs, and Connectors
Pin Signal Description
51 GND
52 AD 36
53 AD 35
54 AD 34
55 AD 33
56 GND
57 +3.3V
58 AD 32
59 NC
60 NC
61 NC
62 GND
63 GND
64 NC
Pin Signal Description
33 PMC IO 33
34 PMC IO 34
35 PMC IO 35
36 PMC IO 36
37 PMC IO 37
38 PMC IO 38
39 PMC IO 39
40 PMC IO 40
41 PMC IO 41
42 PMC IO 42
61
