Hardware Preparation and Installation
2.5

Installing Accessories

2.5.1

Rear Transition Module

The MVME2502 does not support hot swap. Remove power to the rear slot or the system
before installing the module. A PCMI/O Module (PIM) needs to be manually configured and
installed before placing the transition module.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits
or shorten its life.
Before touching the board or electronic components, make sure that you are
working in an ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel
and/or PCB. Deformation of the front panel can cause an electrical short or other
board malfunction.
Board Malfunction
Switches marked as "reserved" might carry production-related functions and can
cause the board to malfunction if their setting is changed.
Do not change settings of switches marked as "reserved". The setting of switches
which are not marked as "reserved" has to be checked and changed before board
installation.
Installation Procedure
1. Turn OFF all equipment and disconnect the power cable from the AC power source.
2. Remove the chassis cover.
3. Remove the filler panel(s) from the appropriate card slot(s) at the rear of the chassis (if
the chassis has a rear card cage).
4. Install the top and bottom edge of the transition module into the rear guides of the
chassis.
5. Ensure that the levers of the two injector/ejectors are in the outward position.
6. Slide the transition module into the chassis until resistance is felt.
7. Move the injector/ejector levers in an inward direction.
