Register Definitions

Watchdog Timer Control/Status Register

The Watchdog Timer Control/Status Register (base + 0A
A read of this register will automatically "pet" the Watchdog Timer and will return
a "1" in bit zero when the Watchdog Timer is enabled. A "0" means the timer is
disabled. Bit 2 returns the current state of the timer. If it is at "1" the timer is
asserted and, if enabled, would assert SYSRESET. The timer must be "pet"
periodically to keep it from asserting its output. Once the timer is unasserted
and pet it will remain unasserted, as long as it is pet within its pet time. The
timer is pet automatically whenever this register is read. Once the timer is
unasserted, it can then be enabled. It will then assert SYSRESET if it is not pet
continuously at least once within its pet time.
Watchdog Timer Control/Status Register (base + 0Ah)
b + A
15
14
13
h
Write
No Effect
Read
Always Returns FFF
DOGENAB = "0" the watchdog timer is disabled. "1" = enabled.
DOGSTATE = "0" the watchdog timer is not asserted. "1" the watchdog timer is
asserted. (If enabled when it is a "1" it will assert SYSRESET). The watchdog
timer can be "pet" by doing a read of this register. The "pet" time is selected by 2
jumpers on the PC board.

Command Register Port 0/2

The Command Register for Port 0/2 (base + 10
contains three bits used to control operating characteristics of the port. If bit 4 of
the Control/Status Register is low ("0"), Port 0 is accessed. If bit 4 is high ("1"),
Port 2 will be accessed. All control bits default to "0" as the reset state.
Bit 0 enables ("1") and disables ("0") an edge event to be reported in the Edge
Interrupt Status Register. If this bit is "1" then any edge event captured in either
the positive or negative edge detect registers will appear in the Edge Interrupt
Status Register. An interrupt will only occur on the backplane (IRQ) if bit 5 in the
Status Register is set. If bit 0 is set to "0" then an edge event will not be
detected in the Edge Interrupt Status Register and can not cause an interrupt.
When this bit is enabled the INTR line on the terminal module is active, and will
be asserted as long as an edge event is captured in either edge detection
register. The state of this bit is returned on a read of the register.
Keysight E1459A/Z2404B User and SCPI Programming Guide
12
11
10
9
8
h
3
2
7
6
5
4
1
1
) can be read or written. It
h
Keysight E1459A Register Definitions
) can be read or written.
h
1
0
DOGENAB
DOGSTATE
DOGENAB
91
