Icom IC-F7010 Series Operating Manual page 55

6
MENU SCREEN
Menu items
In the Menu screen, the items are categorized, as shown below.
C.Tone CH Select
Sets the Continuous tone channel.
Compander
Turns the Compander function ON or OFF.
Priority A CH
Selects the Priority A channel.
Prio A (Rewrite)
Sets a current channel as the Priority A channel.
Priority B CH
Selects the Priority B channel.
Prio B (Rewrite)
Sets a current channel as the Priority B channel.
NAC CH Select
Sets the NAC channel.
RF Power
Selects the output power for each channel.
Channel/Scan
Scan Tag (Scan Add/Del(Tag))
Sets or clears a Scan tag to or from a channel in a Scan list.
Scan List
Sets a Scan list to be scanned.
Scan Start/Stop
Starts or cancels a Scan.
Talkgroup Scan*
Starts or cancels a Talkgroup Scan.
Scramble/Encrypt*
Turns the Voice Scrambler/Encryption function ON or OFF.
CKR Select*
Select the Encryption's Common Key Reference (CKR).
Talk Around
Turns the Talk Around function ON or OFF.
Zone Select
Selects a Zone.
Call Menu
Selects a calling destination and a call type.
Clear Incoming
Clears the received call log from the Incoming list.
Clear Outgoing
Clears the transmit call log from the Outgoing list.
DTMF Autodial
Displays the "DTMF Autodial" screen. The preset DTMF codes are selectable.
Signaling/Call
Group Select
Displays the "Group Select" screen. The preset Group IDs are selectable.
Incoming
Displays a log of the received calls.
Individual Select
Displays the "Individual Select" screen. The preset Individual IDs are selectable.
Message (Short Message)
Displays the "Message" screen. The preset Messages are selectable.
* For only the revision 2.00 or later.
6-3
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-8
p. 6-9
p. 6-9
p. 6-9
p. 6-9
p. 6-9
p. 6-9
p. 6-9
p. 6-9
☞ Continued on the next page
