USER SETTINGS

Setting the Backlight status

You can set the Backlight status.
<Menu operation>
( Menu > Display > Backlight)
1. Push [Menu] to display the Menu screen.
2. Push [Left] or [Right] to select "Display," then push
[OK].
3. Push [Up] or [Down] to select "Backlight," then
push [OK].
4. Push [Up] or [Down] to select an appropriate
option, then push [OK].
For the Portable types:
• OFF: Turns the Backlight continuously OFF.
• ON: Turns the Backlight continuously ON.
• Auto: When any key except [PTT] is pushed, the
Backlight lights for 5 seconds.
For the Mobile types:
• OFF: Turns the Backlight continuously OFF.
• ON: Turns the Backlight continuously ON.
• Auto: Turns the Backlight continuously ON.
When the Dimmer terminal of the D-Sub 25 pin
or Option Connector 22 pin is activated, the
Backlight lights dimly.
5. Hold down [Back] for 1 second to return to the
standby screen.
<Key operation>
Portable:
Push [Backlight] to select the option.
• OFF: Turns the Backlight continuously OFF.
• ON: Turns the Backlight continuously ON.
• Auto: When any key except [PTT] is pushed, the
Backlight lights for 5 seconds.
Mobile:
Push [Backlight] to select the option.
• OFF: Turns the Backlight continuously OFF.
• ON: Turns the Backlight continuously ON.
• Auto: Turns the Backlight continuously ON.
When the Dimmer terminal of the D-Sub 25
pin or Option Connector 22 pin is activated,
the Backlight lights dimly.
